Introduction

This is the documentation for the Proximity API. This is currently a 'living document', and will be continuously expanded as more endpoints are made ready.

For high level design & concepts, consider familiarizing yourself with the following documentation:

Concert Apps Service Design & Architecture

Notes on Retrieving Data

Deleted entries and Suspended Entries

Suspended entries will be returned by all LIST and GET ONE endpoints by default with intervention.

Deleted entries will not be returned by all LIST endpoints, unless the item is specified directly by being given in the ids[] search filter. In this case, this item explicitly requested item will be returned.

The same logic applies to the GET ONE. This will return deleted items if specified explicitly.

Please note, this only applies to endpoints supporting the ids[] filter for the LIST endpoint.

Authentication

To authorize, use both the client key and the authorization token:

# With shell, you can just pass the correct header with each request
curl "api_endpoint_here" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token"

Make sure you use both pieces of information.

Currently, authentication is done via external SSO idP. Once a token has been created, use the token along with the client key to make the API requests. You can obtain your client key using the /clients endpoints.

Authorization: <your-auth-token>
X-Client-Key: <client-key>

Basic schema information

The API follows (with a few exceptions) strict rules regarding REST and idempotency. When creating or saving an object, you must give the complete object. This is part of good REST practice to ensure there are no 'side effects' to other fields that you do not know about. If a field is incorrect, it will give a 400 BAD REQUEST validation error.

However, any fields prefixed with an underscore _ are an exception. These are generated fields are only exist in the return object. Examples of these are:

Calculations, such as a count of inherited objects
The permissions (__permissions__) array, the system admin (__system_admin__) flag on parties.

Permissions

Every object which supports permissions, will return a __permissions__ array. This is an array of permissions that the current logged in user can perform on each object.

Sometimes, this is omitted. The reason for this could be one that follows:

You are a systems administrator, and the permission check bypassed.
It is an object that has no permission control in the system

If this array is NOT given, then assume you have full permission on this object that the system permits.

Auth

These are endpoints that deal with auth events pertaining specifically to Proximity.

An example of these is the guest login. For instance, a guest login is specifically permitted to a party in Proximity and is not related to the Concert Apps suite as a whole.

Note, currently using /auth2 to avoid collision with legacy endpoints. These will eventually be changed to /auth

Without exception, these endpoints all require X-Client-Key to be given, but may or may not require a valid auth token. (Which they may not have)

curl -X POST "https://<api-url>/auth2/guests/initiate" \
  -H "X-Client-Key: client-key" \
  -H "Content-Type: application/json" \
  --data '{
    "dk": "your-client-url-domain",
    "email": "your-email@sixfactor.com"
  }'

A valid response will yield a 202 ACCEPTED.

Please note that a 202 ACCEPTED will be given on all occassions. This is due to standard OWASP security practices to ensure we do not leak any information as to if an email is valid in the system or not, or if that email is permitted guest login (at which point we just indicated to a potential mal-actor that this is a valid login email they can use as an attack vactor)

An Email will then be sent to the email address if:

1) Email identity exists for a party user 2) Party/user has Allow OTP enabled.

In the email, the constructed URL uses the given dk (domain key). This is what you used on the original sign in to find out which client/tenant the vanity domain belongs to. In this case, we use the same to match back to ensure the domain belongs to the tenant, and then construct a URL for the email recipient to go to.

The link will be:

https://[domain-key]/auth/guest?token=[token]

You will use the token (the OTP) in your next request with the API to get a JWT issued.

curl "-X POST https://<api-url>/auth2/guests/confirm" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "token": "the-otp-token"
  }'

A valid response will yield a 200 OK.

{
  "data": {
    "session": {
      "dk": "your domain key",
      "user_id": "user id for the user",
      "email": "the email used",,
      "app_id": "what app this belongs to, ie proximity"
    },
    "access_token": "the-access-token-jwt"
  }
}

Once this operation is complete, use access_token as you would any other JWT.

Assets

NOTE Section still under development - new fields and endpoints will be added as time goes on

Methods for dealing with the Asset object in the system.

Assets are essentially what we understand as locations in the system. They can be configured with different types. This new name is to replace the existing location type in the system.

LIST Assets

curl "https://<api-url>/assets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "deadc0de-1111-4b7a-a990-111111111111",
    "name": "Asset A",
    "description": "Asset A description",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "stats": [{
      "contracts": 10,
      "services": 5,
      "assets": 2,
      "entities": 2
    }],
    "legacy": {
      "building_id": null,
      "location_id": "deadc0de-1111-4b7a-a990-111111111111"
    },
    "is_hidden": false,
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null
  }, {
    "id": "deadc0de-1111-4b7a-a990-222222222222",
    "name": "Building A",
    "description": "Building Desc A",
    "type_id": "deadc0de-2222-4565-92ca-13d996d92ed1",
    "entity_id": null,
    "parent_id": null,
    "stats": [{
      "contracts": 0,
      "services": 0,
      "assets": 0,
      "entities": 0
    }],
    "legacy": {
      "building_id": "deadc0de-1111-4b7a-a990-222222222222",
      "location_id": null
    },
    "is_hidden": false,
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2022-07-02T16:32:48.638Z",
    "deleted_at": null,
    "__permissions__": [
      "asset.view",
      "asset.create",
      "asset.update"
    ]
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of assets, with any given filters applied.

HTTP Request

GET https://<api-url>/assets

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these asset IDs
keywords	null	Filter results by the given keywords. Keywords search across `name`.
type_id	null	Filter results by the given type ID
party_id	null	Filter results by the given party ID
entity_id	null	Filter results by the given entity ID
service_id	null	Filter results by the given service ID
contract_id	null	Filter results by the given contract ID
parent_id	null	Filter results by the given parent ID
exclude_containers	null	Exclude containers from the result set.
include[]	null	Include extra embeded non-resource elements (See list below)
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Include Parameters

Option	Description
stats	Includes object stats. This includes total contracts and services at this point.

Note, entities and assets will be completed following the db upgrades

Sorting fields

Field	Description
name	Sort by name
description	Sort by description
type	Sort by type
entity_name	Sort by entity name
total_contracts	Sort by total contract count
total_parties	Sort by total parties count
created	Sort by create date
updated	Sort by update date

Note, these will be completed following db upgrades

total_entities | Sort by total entities total_assets | Sort by total number of child assets

LIST Asset Types

These are types for the assets. See Asset Type

curl "https://<api-url>/assets/~/types" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Site",
    "config": {
      "require_parent": false,
      "allow_parents": [],
      "can_inherit": false,
      "permit_address": true,
      "permit_geo": true,
      "geo_update_freq": null,
      "is_container": true,
      "is_system": true,
    },
    "created_at": "2021-08-24T15:22:50.557Z",
    "updated_at": "2021-08-24T15:22:50.557Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Building",
    "config": {
      "require_parent": false,
      "allow_parents": [
        "deadc0de-1111-4aaf-a965-e4a096bd3f99",
        "deadc0de-2222-4aaf-a965-e4a096bd3f99"
      ],
      "can_inherit": true,
      "permit_address": true,
      "permit_geo": true,
      "geo_update_freq": null,
      "is_container": true,
      "is_system": true,
    },
    "created_at": "2021-08-24T15:22:50.557Z",
    "updated_at": "2021-08-24T15:22:50.557Z",
    "deleted_at": null
  }]
}

This endpoint retrieves a result set of asset types. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

HTTP Request

GET https://<api-url>/assets/~/types

GET an Asset

curl "https://<api-url>/assets/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "deadc0de-1111-4b7a-a990-111111111111",
    "name": "Asset A",
    "description": "Asset A description",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "phone": "+15551112222",
    "floor_unit": "123",
    "year_built": null,
    "building_floor": "11",
    "num_floors_units": null,
    "strata": null,
    "service_ids": [
      "deadc0de-1111-4849-a096-444444444444",
      "deadc0de-2222-4849-a096-444444444444"
    ],
    "party_ids": [
      "deadc0de-1111-4849-a096-555555555555",
      "deadc0de-2222-4849-a096-555555555555"
    ],
    "address": {
      "unit": "100",
      "street": "station road",
      "locale": "collingham",
      "city": "newark",
      "region": "nottinghamshire",
      "postal": null,
      "country": "gb",
      "lat": 53.144647814788804,
      "long": -0.7552475559891426
    },
    "geo": {
      "lat": null,
      "long": null,
      "radius": null,
      "wkt": null
    },
    "images": [
      "http://image.url"
    ],
    "legacy": {
      "building_id": null,
      "location_id": "deadc0de-1111-4b7a-a990-111111111111"
    },
    "is_hidden": false,
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null,
    "__permissions__": [
      "asset.view",
      "asset.create",
      "asset.update"
    ]
  }
}

In the case that no asset is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific asset by the given id.

HTTP Request

GET https://<api-url>/assets/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the asset to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eAssetNotFound`	The asset could not be found / invalid ID.

Include Parameters

Option	Description
parentage	NOTE Appears to be implemented, please verify. May allow viewing of Assets' parentage.
images	Includes a list of image URLs for this asset

CREATE a new Asset

curl -X POST "https://<api-url>/assets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "A created asset",
    "description": "A brand new asset",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "phone": "+15551112222",
    "floor_unit": "123",
    "year_built": null,
    "building_floor": "11",
    "num_floors_units": null,
    "strata": null,
    "service_ids": [
      "deadc0de-1111-4849-a096-444444444444",
      "deadc0de-2222-4849-a096-444444444444"
    ],
    "party_ids": [
      "deadc0de-1111-4849-a096-555555555555",
      "deadc0de-2222-4849-a096-555555555555"
    ],
    "address": {
      "unit": "100",
      "street": "station road",
      "locale": "collingham",
      "city": "newark",
      "region": "nottinghamshire",
      "postal": null,
      "country": "gb",
      "lat": 53.144647814788804,
      "long": -0.7552475559891426
    },
    "geo": null,
    "is_hidden": false,
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created asset",
    "description": "A brand new asset",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "phone": "+15551112222",
    "floor_unit": "123",
    "year_built": null,
    "building_floor": "11",
    "num_floors_units": null,
    "strata": null,
    "service_ids": [
      "deadc0de-1111-4849-a096-444444444444",
      "deadc0de-2222-4849-a096-444444444444"
    ],
    "party_ids": [
      "deadc0de-1111-4849-a096-555555555555",
      "deadc0de-2222-4849-a096-555555555555"
    ],
    "address": {
      "unit": "100",
      "street": "station road",
      "locale": "collingham",
      "city": "newark",
      "region": "nottinghamshire",
      "postal": null,
      "country": "gb",
      "lat": 53.144647814788804,
      "long": -0.7552475559891426
    },
    "geo": null,
    "is_hidden": false,
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "asset.view",
      "asset.create",
      "asset.update"
    ]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an asset with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/assets

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type_id	uuid	Valid asset type ID Entity Type	Yes
entity_id	uuid	Valid entity ID	Yes
parent_id	uuid	Valid parent ID, depending on restrictions given by type	Yes
phone	string	Valid e164 number format	Yes
floor_unit	string	Max length 150, unit number	Yes
year_built	string	Max length 50, if building, year built. Will move to custom field.	Yes
building_floor	string	Max length 50. Will move to custom field.	Yes
num_floors_units	string	Max length 50. For buildings, number of floors or units. Will move to custom field.	Yes
stata	string	Max length 50. Stata ID for building. Will move to custom fields	Yes
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
party_ids	uuid[]	Valid party ids. Use empty array for empty.	No
address	Address	If type permits address, otherwise `null`	Yes
geo	GeoZone	If type permits geo, otherwise `null`	Yes
is_hidden	boolean	True if this asset is hidden
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAssetTypeNotFound`	Asset type ID given could not be found
400 BAD REQUEST	`eAddressNotPermitted`	Asset type does not permit an address
400 BAD REQUEST	`eGeoNotPermitted`	Asset type does not permit geo
400 BAD REQUEST	`eParentNotPermitted`	Asset type does not permit a parent, or a parent of the type given.
400 BAD REQUEST	`eParentRequired`	Asset type requires a parent
400 BAD REQUEST	`eEntityNotPermitted`	Asset type does not permit entities assigned to it.
400 BAD REQUEST	`eEntityNotFound`	Entity ID given could not be found
400 BAD REQUEST	`eAssetRequiresEntity`	Asset requires an entity
400 BAD REQUEST	`eAssetRequiresLocationInfo`	Asset requires location information (ie, geo or address)
400 BAD REQUEST	`eAssetRequiresParent`	Asset requires a parent
400 BAD REQUEST	`eContainerTypeChangeRestricted`	You cannot change an asset from a container type to a non-container type and vice versa
400 BAD REQUEST	`eAssignedObjectsNotPermitted`	This asset type does not permit assigned objects.
400 BAD REQUEST	`eAttemptSaveWithMissingParties`	One or more of the parties given do not exit
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	One or more of the services given do not exit

UPDATE an Asset

curl -X PUT "https://<api-url>/assets/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "An updated asset",
    "description": "An updated new asset",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "phone": "+15551112222",
    "floor_unit": "123",
    "year_built": null,
    "building_floor": "11",
    "num_floors_units": null,
    "strata": null,
    "service_ids": [
      "deadc0de-1111-4849-a096-444444444444",
      "deadc0de-2222-4849-a096-444444444444"
    ],
    "party_ids": [
      "deadc0de-1111-4849-a096-555555555555",
      "deadc0de-2222-4849-a096-555555555555"
    ],
    "address": {
      "unit": "100",
      "street": "station road",
      "locale": "collingham",
      "city": "newark",
      "region": "nottinghamshire",
      "postal": null,
      "country": "gb",
      "lat": 53.144647814788804,
      "long": -0.7552475559891426
    },
    "geo": {
      "lat": 53.144647814788804,
      "long": -0.7552475559891426,
      "radius": 343,
      "wkt": "POLYGON(23,343,234,23)"
    },
    "is_hidden": false,
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created asset",
    "description": "A brand new asset",
    "type_id": "deadc0de-1111-4aaf-a965-e4a096bd3f99",
    "entity_id": "deadc0de-1111-4b7a-a990-777777777777",
    "parent_id": "deadc0de-1111-4b7a-a990-222222222222",
    "phone": "+15551112222",
    "floor_unit": "123",
    "year_built": null,
    "building_floor": "11",
    "num_floors_units": null,
    "strata": null,
    "service_ids": [
      "deadc0de-1111-4849-a096-444444444444",
      "deadc0de-2222-4849-a096-444444444444"
    ],
    "party_ids": [
      "deadc0de-1111-4849-a096-555555555555",
      "deadc0de-2222-4849-a096-555555555555"
    ],
    "address": {
      "unit": "100",
      "street": "station road",
      "locale": "collingham",
      "city": "newark",
      "region": "nottinghamshire",
      "postal": null,
      "country": "gb",
      "lat": 53.144647814788804,
      "long": -0.7552475559891426
    },
    "geo": {
      "lat": 53.144647814788804,
      "long": -0.7552475559891426,
      "radius": 343,
      "wkt": "POLYGON(23,343,234,23)"
    },
    "is_hidden": false,
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "asset.view",
      "asset.create",
      "asset.update"
    ]
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing asset with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/assets/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the asset to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type_id	uuid	Valid asset type ID Entity Type	Yes
entity_id	uuid	Valid entity ID	Yes
parent_id	uuid	Valid parent ID, depending on restrictions given by type	Yes
phone	string	Valid e164 number format	Yes
floor_unit	string	Max length 150, unit number	Yes
year_built	string	Max length 50, if building, year built. Will move to custom field.	Yes
building_floor	string	Max length 50. Will move to custom field.	Yes
num_floors_units	string	Max length 50. For buildings, number of floors or units. Will move to custom field.	Yes
stata	string	Max length 50. Stata ID for building. Will move to custom fields	Yes
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
party_ids	uuid[]	Valid party ids. Use empty array for empty.	No
contract_ids	uuid[]	Valid contract ids. Use empty array for empty.	No
address	Address	If type permits address, otherwise `null`	Yes
geo	GeoZone	If type permits geo, otherwise `null`	Yes
is_hidden	boolean	True if this asset is hidden
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAssetNotFound`	Asset ID given could not be found
400 BAD REQUEST	`eAssetTypeNotFound`	Asset type ID given could not be found
400 BAD REQUEST	`eAddressNotPermitted`	Asset type does not permit an address
400 BAD REQUEST	`eGeoNotPermitted`	Asset type does not permit geo
400 BAD REQUEST	`eParentNotPermitted`	Asset type does not permit a parent, or a parent of the type given.
400 BAD REQUEST	`eParentRequired`	Asset type requires a parent
400 BAD REQUEST	`eEntityNotPermitted`	Asset type does not permit entities assigned to it.
400 BAD REQUEST	`eEntityNotFound`	Entity ID given could not be found
400 BAD REQUEST	`eAssetRequiresEntity`	Asset requires an entity
400 BAD REQUEST	`eAssetRequiresLocationInfo`	Asset requires location information (ie, geo or address)
400 BAD REQUEST	`eAssetRequiresParent`	Asset requires a parent
400 BAD REQUEST	`eContainerTypeChangeRestricted`	You cannot change an asset from a container type to a non-container type and vice versa
400 BAD REQUEST	`eAssignedObjectsNotPermitted`	This asset type does not permit assigned objects.
400 BAD REQUEST	`eAttemptSaveWithMissingParties`	One or more of the parties given do not exit
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	One or more of the services given do not exit

BATCH UPDATE Assets

curl -X PATCH "https://<api-url>/assets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "entity_id": "2bd2846a-018c-4131-92eb-fbbba8ac4eeb",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "entity_id": "1a48ea14-24a7-420f-998a-78d498034cf6",
      "parent_id": "910abce5-2846-44ab-84c8-cf8a0581c197",
      "party_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
      "party_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
      "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
      "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "entity_id": null,
      "parent_id": null,
      "suspended_at": null,
      "deleted_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "entity_id": "2bd2846a-018c-4131-92eb-fbbba8ac4eeb",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "entity_id": "1a48ea14-24a7-420f-998a-78d498034cf6",
    "parent_id": "910abce5-2846-44ab-84c8-cf8a0581c197",
    "party_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
    "party_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
    "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
    "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "entity_id": null,
    "suspended_at": null,
    "deleted_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch Asset fields. To help maintain the integrity of an asset, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The party, contract, and service ID fields will allow assigning and unassigning party, contract, and services from the given entity. Note, only one can be given at a time for each asset.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/assets

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
parent_id	uuid	Valid parent id	Yes
entity_id	uuid	Valid entity id	Yes
party_id_assign	uuid	None	Yes, but will no-op
party_id_unassign	uuid	None	Yes, but will no-op
service_id_assign	uuid	None	Yes, but will no-op
service_id_unassign	uuid	None	Yes, but with no-op
suspended_at	datetime	Will de-activate (suspend) the asset if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the asset if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' assets endpoint.

Config

Returns the current configuration for the environment based on the current signed in user's permissions.

This includes various information which can be used to configure the environment the frontend provides to that user, such as:

Theme
Vocabulary (ie, name changes)
Base permissions for current users
Phases, messages, etc
Tab and configurations

GET config

curl "https://<api-url>/config" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

{
  "data": {
    "theme": [{
      "key": "login.logo",
      "value": "https://via.placeholder.com/250",
      "domain": "login"
    }, {
      "key": "bg.color",
      "value": "#fefefe",
      "domain": "crud-admin"
    }],
    "phrasing": [{
      "key": "login.welcome",
      "value": "Welcome to the custom text for the login page",
      "locale": "en-CA"
    }],
    "vocab": [{
      "key": "customer",
      "locale": "en-CA",
      "singular": "Contact",
      "plural": "Contacts"
    }, {
      "key": "asset",
      "locale": "en-CA",
      "singular": "Location",
      "plural": "Locations"
    }],
    "settings": [{
      "key": "some.key.1",
      "value": "configuration setting 1",
      "domain": "login"
    }],
    "permissions": [
      "contracts.create",
      "contracts.view"
    ]
  }
}

Returns all the current configuration for Proximity for the given tenant & signed in user.

Theme

This current theme information provided for this Proximity instance for the tenant.

Phrasing

These are custom messages and phrases specific to the given tenant

Vocab

These are changes in system names for the given tenant. For instance, Assets could be set to Locations.

settings

These are settings specific to the current user

permissions

A list of permissions for the current user. These are a collection of all permissions avaiable. These do not include permission access that is also derived from the Operational Group or Groups the current user is also in.

GET Theme Config

curl "https://<api-url>/config/theme" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

{
  "data": [{
    "key": "login.logo",
    "value": "https://via.placeholder.com/250",
    "domain": "login"
  }, {
    "key": "bg.color",
    "value": "#fefefe",
    "domain": "crud-admin"
  }]
}

Contracts

NOTE Section still under development

Methods for dealing with the Contract object in the system.

All contracts will have a provider and a consumer. These fields will come soon as the data model from the existing system is upgraded. (Currently only one-sided behaviour is permitted limited to entities only.)

Note on development

Currently, this endpoint is providing a 'facade' for the legacy contract endpoint in the system. The id for the contracts are the same as the contract_id for the existing contracts. Legacy endpoints at this juncture can still be used interchangably, but newer functionality should be preferred where possible as older legacy endpoints will be deprecated as the data model is migrated.

LIST contracts

curl "https://<api-url>/contracts" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Contract A",
    "description": "Contract description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "stats": [{
      "entites": 4,
      "assets": 2
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Contract B",
    "starts_at": null,
    "expires_at": null,
    "url": null,
    "stats": [{
      "entities": 0,
      "assets": 0
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "contracts.view",
      "contracts.create",
      "contracts.update"
    ]
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of contracts, with any given filters applied.

HTTP Request

GET https://<api-url>/contracts

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these contract IDs
party_id	null	Filter results for those associated with this party ID
service_id	null	Filter results for those associated with this service ID
asset_id	null	Filter results for those associated with this contract ID
entity_ids	null	Filter results for those associated with these entity IDs (string[])
keywords	null	Filter results by the given keywords. Keywords search across `name`.
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
counts	Includes object count totals, including resources and assets.

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
total_assets	Sort by total asset count
total_entities	Sort by total entities count
expiry	Sort by expiry
created	Sort by create date
updated	Sort by update date

LIST Contract Roles

These are role associations for the contract's contacts and owners. See Contract Role Type

curl "https://<api-url>/contracts/~/roles" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Customer Success",
    "description": "Some description",
    "type": "owner",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Primary Contact",
    "description": "Some description",
    "type": "contact",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of contract roles. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

HTTP Request

GET https://<api-url>/contracts/~/roles

GET a Contract

curl "https://<api-url>/contracts/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Contract A",
    "description": "Contract description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "party_ids": [
      "deadc0de-a110-4e58-a166-73c6e25cab04",
      "deadc0de-ba81-45f3-a6ae-321d893ec3df"
    ],
    "service_ids": [
      "deadc0de-5555-4849-a096-5800072f28c2",
      "deadc0de-5555-4b26-89eb-4ed6de8baa53"
    ],
    "asset_ids": [
      "deadc0de-7777-4849-a096-5800072f28c2",
      "deadc0de-7777-4b26-89eb-4ed6de8baa53"
    ],
    "entity_ids": [
      "deadc0de-8888-4849-a096-5800072f28c2",
      "deadc0de-8888-4b26-89eb-4ed6de8baa53"
    ],
    "media_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "contracts.view",
      "contracts.create",
      "contracts.update"
    ]
  }
}

In the case that no contract is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific contract by the given id.

HTTP Request

GET https://<api-url>/contracts/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the contract to retrieve

Embed/Include Parameters

Option	Description
counts	Includes object count totals, including resources and assets.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eContractNotFound`	The contract could not be found / invalid ID.

CREATE a new Contract

curl -X POST "https://<api-url>/contracts" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "A created contract",
    "description": "Created contract description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "party_ids": [
      "deadc0de-a110-4e58-a166-73c6e25cab04",
      "deadc0de-ba81-45f3-a6ae-321d893ec3df"
    ],
    "service_ids": [
      "deadc0de-5555-4849-a096-5800072f28c2",
      "deadc0de-5555-4b26-89eb-4ed6de8baa53"
    ],
    "asset_ids": [
      "deadc0de-7777-4849-a096-5800072f28c2",
      "deadc0de-7777-4b26-89eb-4ed6de8baa53"
    ],
    "entity_ids": [
      "deadc0de-8888-4849-a096-5800072f28c2",
      "deadc0de-8888-4b26-89eb-4ed6de8baa53"
    ],
    "media_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created Entity",
    "description": "Created Entity description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "party_ids": [
      "deadc0de-a110-4e58-a166-73c6e25cab04",
      "deadc0de-ba81-45f3-a6ae-321d893ec3df"
    ],
    "service_ids": [
      "deadc0de-5555-4849-a096-5800072f28c2",
      "deadc0de-5555-4b26-89eb-4ed6de8baa53"
    ],
    "asset_ids": [
      "deadc0de-7777-4849-a096-5800072f28c2",
      "deadc0de-7777-4b26-89eb-4ed6de8baa53"
    ],
    "entity_ids": [
      "deadc0de-8888-4849-a096-5800072f28c2",
      "deadc0de-8888-4b26-89eb-4ed6de8baa53"
    ],
    "media_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "contracts.view",
      "contracts.create",
      "contracts.update"
    ]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an entity with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

Media IDs can be added from uploaded media via the media endpoint. This design will come later. Use an empty array for now

HTTP Request

POST https://<api-url>/entities

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
starts_at	datetime	Use ISO8601 compliant timestamp	Yes
expires_at	datetime	Use ISO8601 compliant timestamp	Yes
url	string	Max length 1000	Yes
owners	PartyAssociation[]	Use empty array for empty	No
contacts	PartyAssociation[]	Use empty array for empty	No
party_ids	uuid[]	Valid party ids. Use empty array to empty.	No
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
asset_ids	uuid[]	Valid asset ids. Use empty array for empty.	No
entities_ids	uuid[]	Valid entity ids. Use empty array for empty.	No
media_ids	uuid[]	Valid media ids. Use empty array for empty.	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	Some of the service ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingParties`	Some of the parties ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingRoles`	Some of the role ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingContacts`	Some or all of the contacts ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingMedia`	Some or all of the media ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingEntities`	Some or all of the entity ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingAssets`	Some or all of the asset ids you've given do not exist

UPDATE a Contract

curl -X PUT "https://<api-url>/contracts/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "An updated contract",
    "description": "Updated contract description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "party_ids": [
      "deadc0de-a110-4e58-a166-73c6e25cab04",
      "deadc0de-ba81-45f3-a6ae-321d893ec3df"
    ],
    "service_ids": [
      "deadc0de-5555-4849-a096-5800072f28c2",
      "deadc0de-5555-4b26-89eb-4ed6de8baa53"
    ],
    "asset_ids": [
      "deadc0de-7777-4849-a096-5800072f28c2",
      "deadc0de-7777-4b26-89eb-4ed6de8baa53"
    ],
    "entity_ids": [
      "deadc0de-8888-4849-a096-5800072f28c2",
      "deadc0de-8888-4b26-89eb-4ed6de8baa53"
    ],
    "media_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "An updated contract",
    "description": "Updated contract description",
    "starts_at": "2022-01-01T12:35:00.000Z",
    "expires_at": "2023-01-01T12:35:00.000Z",
    "url": "https://drive.google.com/some-document.pdf",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "party_ids": [
      "deadc0de-a110-4e58-a166-73c6e25cab04",
      "deadc0de-ba81-45f3-a6ae-321d893ec3df"
    ],
    "service_ids": [
      "deadc0de-5555-4849-a096-5800072f28c2",
      "deadc0de-5555-4b26-89eb-4ed6de8baa53"
    ],
    "asset_ids": [
      "deadc0de-7777-4849-a096-5800072f28c2",
      "deadc0de-7777-4b26-89eb-4ed6de8baa53"
    ],
    "entity_ids": [
      "deadc0de-8888-4849-a096-5800072f28c2",
      "deadc0de-8888-4b26-89eb-4ed6de8baa53"
    ],
    "media_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "contracts.view",
      "contracts.create",
      "contracts.update"
    ]
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing contract with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

Media IDs can be added from uploaded media via the media endpoint. This design will come later. Use an empty array for now

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/contract/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the contract to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
starts_at	datetime	Use ISO8601 compliant timestamp	Yes
expires_at	datetime	Use ISO8601 compliant timestamp	Yes
url	string	Max length 1000	Yes
owners	PartyAssociation[]	Use empty array for empty	No
contacts	PartyAssociation[]	Use empty array for empty	No
party_ids	uuid[]	Valid party ids. Use empty array to empty.	No
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
asset_ids	uuid[]	Valid asset ids. Use empty array for empty.	No
entities_ids	uuid[]	Valid entity ids. Use empty array for empty.	No
media_ids	uuid[]	Valid media ids. Use empty array for empty.	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eContractNotFound`	Entity ID given could not be found
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	Some of the service ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingParties`	Some of the parties ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingRoles`	Some of the role ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingContacts`	Some or all of the contacts ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingEntities`	Some or all of the entity ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingAssets`	Some or all of the asset ids you've given do not exist

BATCH UPDATE Contracts

curl -X PATCH "https://<api-url>/contracts" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "party_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
      "party_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
      "asset_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
      "asset_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
      "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
      "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
      "entity_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
      "entity_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
      "suspended_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "party_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
    "party_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
    "asset_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
    "asset_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
    "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
    "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
    "entity_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
    "entity_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
    "suspended_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch contract fields. To help maintain the integrity of a contract, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The party & service ID fields will allow assigning and unassigning party and services from the given entity. Note, only one can be given at a time for each contract.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/contracts

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
party_id_assign	uuid	None	Yes, but will no-op
party_id_unassign	uuid	None	Yes, but will no-op
service_id_assign	uuid	None	Yes, but will no-op
service_id_unassign	uuid	None	Yes, but with no-op
entity_id_assign	uuid	None	Yes, but will no-op
entity_id_unassign	uuid	None	Yes, but with no-op
asset_id_assign	uuid	None	Yes, but will no-op
asset_id_unassign	uuid	None	Yes, but with no-op
suspended_at	datetime	Will de-activate (suspend) the entity if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the entity if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' datazones endpoint.

DELETE a Contract

curl -X DELETE "https://<api-url>/contracts/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given contract by id.

HTTP Request

DELETE https://<api-url>/contracts/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eContractNotFound`	The contract could not be found / invalid ID.

Datazones

Methods for dealing with the DataZone object in the system.

Datazones in the system have 2 possible base types (See DataZone Types)

Geo
Commercial

A geo datazone is a zone described by various geo parameters. These include

Longitude & Latitude, as a single point (via the Geo object)
Longitude & Latitude, as a radius (via the Geo object)
WKT (Well-known-text) a geometric polygon shape (via the Geo object)
Locations via addresses (See Address)

The geo datazone an also have the following properties:

Specific addresses
Specific geo data/zones
Specific entities
Specific contracts

A commercial datazone can have the following propreties:

Specified industries that is applies to
Specific entities
Specific contracts

The following hard rules are applied:

A Commercial datazone cannot contain any geo information, addresses.
A Geo datazone cannot contain at industries.

See the Groups section, and the diagram within to better understand how datazones fall into the bigger picture of groups and operational groups.

Dynamic & static datazones

The is_dynamic flag can be applied to both types of datazone.

When set to true on the commercial type, industries are used to gauge the commercial zone and the explicit contract_ids and entity_ids are ignored. Please note, these are kept, and can still be saved and edited. This is to permit easier modification, and the ability to switch between the two modes without data loss.

For the geo datazone type, setting the is_dynamic field will mean that the datazone will be using the geozones belonging to it, versus the civic addresses in the addresses array.

Pulling external data

Pull outside data has to be done using the resource endpoints of the data you wish to achieve. The API has been deliberately designed this way (Domain Driven & Bounded Context), to enable better future scaling within a microservice based architecture.

Where to go for the external data

For DataZone Type	Data	Where to go
`geo`	`geocode`	This endpoint, namely `/datazones/{id}/geozones`
`commercial`	`entities`	Endpoint: `/entities`
`commercial`	`contracts`	Endpoint: `/contracts`
`commercial`	`industries`	Endpoint `/industries`

Differences between list resource and single resource

In the interest of performance and scaling, the resource representation in the list response is shortened compared to the full resource response as seen in the "single" get, post, and put responses.

Items that do not exist on the list response include:

owner_ids
addresses

LIST DataZones

curl "https://<api-url>/datazones" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "is_dynamic": true,
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "stats": [{
      "operational": 4
    }],
    "geo_zones": [],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.commercial.update"
    ]
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Calgary",
    "type": "geo",
    "is_dynamic": false,
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "stats": [{
      "operational": 2
    }],
    "geo_zones": [{
      "id": "bc9d1a95-b6d1-4e8e-99a3-408b338931a0",
      "name": "My office",
      "long": 100.213,
      "lat": 48.234,
      "radius": 0,
      "wkt": null
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.geo.update"
    ]
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "items": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }]
}

This endpoint retrieves a result set of datazones, with any given filters applied.

By default, this payload does not include any stats, since this operational can be expensive. Adding counts to the include array will cause this to be calculated and returned.

HTTP Request

GET https://<api-url>/datazones

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these contract IDs
type	null	Filter results by the given type ID
keywords	null	Filter results by the given keywords. Keywords search across `name` and `description`. Min characters 2.
entity_id	null	Filter the results by the datazones with these entities.
include[]	null	Include extra embeded non-resource elements (See list below)
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
counts	Includes all the inherited object counts from users, territories, & features.
geozones	Includes all available geozones

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
total_operational_groups	Sort by total operational groups
created	Sort by create date
updated	Sort by update date

Note, sorting on individual object counts will come at a future time

LIST GeoZones for DataZone

curl "https://<api-url>/datazones/6fd5b5c4-0978-49f6-b301-85f60434c1b9/geozones" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found. This data is absolute and contains no pagination or sorting.

{
  "data": [{
    "id": "a0ece4bf-5d87-4d4c-89e8-f06fd0074c5f",
    "name": "Downtown vancouver",
    "long": null,
    "lat": null,
    "radius": null,
    "wkt": "POLYGON(100.2341,48.3425,101.342,48.567)"
  }, {
    "id": "bc9d1a95-b6d1-4e8e-99a3-408b338931a0",
    "name": "My office",
    "long": 100.213,
    "lat": 48.234,
    "radius": 0,
    "wkt": null
  }, {
    "id": "6893814e-6f3e-4e38-bf2a-cd60dd2fe1c4",
    "name": "Somewhere else",
    "long": 99.111,
    "lat": 44.222,
    "radius": 30,
    "wkt": null
  }]
}

This endpoint retrieves a result set of GeoZones, belonging to a specifc datazone of type geo.

Requesting this of a datazone that is commercial will always return an empty dataset.

HTTP Request

GET https://<api-url>/datazones/<id>/geozones

GET a DataZone

curl "https://<api-url>/datazones/abfe045b-814e-4d31-98f5-f3d0a23437f1" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "is_dynamic": true,
    "addresses": [],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

The baseline response for a geo object with addresses

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "is_dynamic": false,
    "addresses": [{
      "name": "Center",
      "unit": "100",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "lat": "52.023432",
      "long": "-0.126345"
    }, {
      "country": "gb",
      "region": "lincolnshire"
    }],
    "industry_ids": [],
    "contract_ids": [],
    "entity_ids": [],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.commercial.update",
      "datazone.commercial.remove"
    ]
  }
}

An expanded result will include all the sub objects and their counts. Note, that although the counts will apply to the sub objects, the expanded "GET ONE" form with the industry, entity etc ids, will only apply to the parent object.

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "is_dynamic": true,
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "stats": [{
      "operational": 4
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.commercial.update",
      "datazone.commercial.remove"
    ]
  }
}

In the case that no datazones are found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific datazone by the given id.

HTTP Request

GET https://<api-url>/datazones/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the datazone to retrieve
include[]	null	Include extra embeded non-resource elements.

Embed/Include Parameters

Option	Description
counts	Includes all the inherited object counts from users, territories, & features.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eDataZoneNotFound`	The datazone could not be found / invalid ID.

CREATE a DataZone

curl -X POST "https://<api-url>/datazones" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Vancouver Greater",
    "type": "commercial",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "is_dynamic": true,
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "suspended_at": null,
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "is_dynamic": true,
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.commercial.update",
      "datazone.commercial.remove"
    ]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a datazone with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/datazones

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type	DataZone Type	One of the valid types	No
is_dynamic	boolean	If the datazone is dynamic or not.	No
addresses	Address[]	For `geo` only, use empty `[]` otherwise	No
owner_ids	uuid[]	Valid party IDs (Can use legacy user ids)	No
industry_ids	array of uuids	Valid Industry IDs	No
entity_ids	array of uuids	Valid Entity IDs	No
contract_ids	array of uuids	Valid Contract IDs	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAttemptTypeChange`	You cannot change the datazone type once created.
400 BAD REQUEST	`eAttemptSaveWithMissingContracts`	One or more of the contract_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingIndustries`	One or more of the industry_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingEntities`	One or more of the entity_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	One or more of the owner_ids you've given do not exist.

UPDATE a DataZone

curl -X PUT "https://<api-url>/datazones/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Vancouver Greater",
    "type": "commercial",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "is_dynamic": true,
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "suspended_at": null,
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Vancouver Greater",
    "type": "commercial",
    "is_dynamic": true,
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "industry_ids": [
      "975ce5ab-3a37-4a4f-a50f-82df38897d43"
    ],
    "entity_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "contract_ids": [
      "eeb586b1-5095-4ca8-96d4-288446cea05c"
    ],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "datazone.commercial.view",
      "datazone.commercial.update",
      "datazone.commercial.remove"
    ]
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing datazone with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/datazones/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the datazone to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type	DataZone Type	One of the valid types	No
is_dynamic	boolean	Is the datazone dynamic or not	No
addresses	Address[]	For `geo` only, use empty `[]` otherwise	No
owner_ids	uuid[]	Valid party IDs (Can use legacy user ids)	No
industry_ids	array of uuids	Valid Industry IDs	No
entity_ids	array of uuids	Valid Entity IDs	No
contract_ids	array of uuids	Valid Contract IDs	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eDataZoneNotFound`	The datazone could not be found / invalid ID.
400 BAD REQUEST	`eAttemptTypeChange`	You cannot change the datazone type once created.
400 BAD REQUEST	`eAttemptSaveWithMissingContracts`	One or more of the contract_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingIndustries`	One or more of the industry_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingEntities`	One or more of the entity_ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	One or more of the owner_ids you've given do not exist.

UPDATE GeoZones for a DataZone

curl -X PUT "https://<api-url>/datazones/6fd5b5c4-0978-49f6-b301-85f60434c1b9/geozones" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "a0ece4bf-5d87-4d4c-89e8-f06fd0074c5f",
      "name": "Downtown Vancouver",
      "long": null,
      "lat": null,
      "radius": null,
      "wkt": "POLYGON(100.2341,48.3425,101.342,48.567)"
    }, {
      "id": "bc9d1a95-b6d1-4e8e-99a3-408b338931a0",
      "name": "Office",
      "long": 100.213,
      "lat": 48.234,
      "radius": 0,
      "wkt": null
    }, {
      "id": "6893814e-6f3e-4e38-bf2a-cd60dd2fe1c4",
      "name": "Other place",
      "long": 99.111,
      "lat": 44.222,
      "radius": 30,
      "wkt": null
    }]
  }'

Note, this endpoint is idempotent, and expects an attribute data containing an array of all geozones for that datazone. A valid response will be a 200 OK, with the new state of geozones as an array

{
  "data": [{
    "id": "a0ece4bf-5d87-4d4c-89e8-f06fd0074c5f",
    "name": "Downtown Vancouver",
    "long": null,
    "lat": null,
    "radius": null,
    "wkt": "POLYGON(100.2341,48.3425,101.342,48.567)"
  }, {
    "id": "bc9d1a95-b6d1-4e8e-99a3-408b338931a0",
    "name": "Office",
    "long": 100.213,
    "lat": 48.234,
    "radius": 0,
    "wkt": null
  }, {
    "id": "6893814e-6f3e-4e38-bf2a-cd60dd2fe1c4",
    "name": "Other place",
    "long": 99.111,
    "lat": 44.222,
    "radius": 30,
    "wkt": null
  }]
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint is idempontent and will update all the geozones for the given datazone.

The body should be an array of all geozones within the attribute data. New attributes should have id set to null. Existing attributes should have their existing ids, and will be updated. Any existing geozones excluded from the list will be deleted.

If you try to update a geozone with an ID that does not exist (or exists for another datazone), this ID will be replaced.

The response from this method gives the new state of geozones for the datazones, will all IDs completed.

To summarize:

Geozone in list	Action
`id` set to `null`	Create this new geozone for the the datazone
`id` set to existing uuid	Update this geozone
Geozone is omitted	Geozone deleted.

HTTP Request

PUT https://<api-url>/datazones/<id>/geozones

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the datazone to update the geozones for

Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	If not `null`, valid ID	Yes, will create.
name	string	Less than 150 chars	Yes
long	number	Between -180 and 180	Yes, if `wkt` given
lat	number	Between -90 and 90	Yes, if `wkt` given
radio	integer	Above 0	Yes
wkt	string	Must be given in long/lat are null	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eDataZoneNotFound`	The datazone could not be found / invalid ID.
400 BAD REQUEST	`eAttemptSaveGeoOnIncorrectType`	You are trying to update geozones on a `commercial` type datazone. This is not permitted.

BATCH UPDATE DataZones

curl -X PATCH "https://<api-url>/datazones" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "entity_id_assign": "b08e291e-2aee-4777-adf2-60c1115fd84a",
      "entity_id_unassign": "e74fe103-8bf6-4e98-be26-33a13c373ebb",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "suspended_at": null,
      "deleted_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "entity_id_assign": "b08e291e-2aee-4777-adf2-60c1115fd84a",
    "entity_id_unassign": "e74fe103-8bf6-4e98-be26-33a13c373ebb",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "suspended_at": null,
    "deleted_at": null
  }]
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch DataZone fields. To help maintain the integrity of DataZones, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/datazones

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
suspended_at	datetime	Will de-activate (suspend) the datazone if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the datazone if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' datazones endpoint.

DELETE a DataZone

curl -X DELETE "https://<api-url>/datazones/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given datazone by id.

HTTP Request

DELETE https://<api-url>/datazones/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eDataZoneNotFound`	The datazone could not be found / invalid ID.

Dynamic Fields

Dynamic fields are an extensive method of allowing custom fields and values to individual relationships in the system. Although dynamic, the sub-system has been restricted to various types for database query efficiency (for things such as reporting on aggregate values), and to retain our complex IAM system.

Core concepts

Taking inspiration from the basic building blocks of English grammar, each relationship for which a custom field exists is described in two parts:

The SUBJECT (the main object this relates to)
The OBJECT (the other object whence this subject has a relationship with)

Subjects

Currently, the following subjects are supported:

Assets

Objects

The following objects are supported:

Assets
Contracts
Services
(None)

When the object and subject type match (ie, asset and an asset), it is asummed that the asset has a relationship with another asset (such as the standard asset heirachy, ie sites, buildings, locations). When the object is vacant, it is assumed this is a dynamic field belonging to the base object itself, and is not part of any relationship.

Fields

These are the dynamic fields as defined. They can be used across the system for any combination of subject or object.

The following field types are supported.

Field Type	Customization Options	Schema
text	max length, multiline or not.	`{ max: number, multiline: boolean }`
number	min and max values, scalefactor for decimals	`{ max: number, min: number, scalefactor: number }`
dateOnly	none	`{}`
dateTime	none	`{}`
dropdown	options, key/value array	`{ options: { key: string, value: string}[]}`
multiselect	options, key/value array	`{ options: { key: string, value: string}[]}`
checkbox	none	`{}`

Values

These are the values for the fields. The value contains the subject/object combination, as well as a link to the field, and the value itself.

The following value formats will be returned for the given field type:

Field Type	Value Type	Explanation
text	string
number	integer	For precision (ie decimal shift) see config of field
dateOnly	string	ISO formatted date string
dateTime	Timestamp	ISO 8601 formatted
dropdown	string	Key for the selected option
multiselect	string	Keys for the selection options, comma separated.
checkbox	boolean

Layouts

These are the template layouts used to display the custom screen as used by the tabs.

Currently, you can load and edit layouts, and lookup a specific layout for a given OBJECT and a SUBJECT (currently given as forAssetId).

When using forAssetId, the API endpoint will return exactly one layout. This will either be:

1) A matching layout for the assicated Entity's industry 2) If this does not exist, then the default layout for this subject(asset)/object combination is given.

Cards

Layouts contain cards, which are collections (Groups) of content.

Items

These are the individual pieces of content within a card. They each have a type:

field
contractExpiry (contract/accounts only)
skillsets (parties only)
summary

If field is given, then field_id cannot be null. This means that this item is a dynamic field.

Every other type must have a null in the field_id column. These other types signify to the frontend where specific content should be places in that part of the card, instead of a dynamic field

For instance, an item with the type skillset, will mean to load the current party's skillsets in this place for editing. The template for this editing table would be held within the frontend, and then the frontend would handle updates via the existing skill infrastructure and outside of dynamic fields, because this is not a dynamic field.

This allows non-dynamic field content to be interlaced around dynamic fields

Important note

There is no validation at this time to ensure that an item type belongs in the current subject/object that this layout belongs to. This is entirely down to the frontend because it is outside of the dynamic field system. To ensure system integrity, the following should be put in place:

Ensure that only relavent item types can be selected for the current subject/object type
If an invalid type is received, ignore it, and log an error.

Working with 'industries'

A different layout is to be presented depending on the asset entities' industry. Note, that one layout can have several industries, but it cannot have an industry belonging to another layout. If you try to add an industry that is already in use from an existing layout, then the save request will be refused.

Layout and Field relationship

Input/output schema information

This area of the system is new, and some of the schema definitions may change. For the latest schema, visit the files under this folder.

Once the schema has stablized, it will be abstracted out here.

concert-services repo - proximity/api/src/modules/dynamicfields/lib/schemas - proximity/api/src/modules/dynamicfields/routes.ts

LIST Layouts

curl "https://<api-url>/dynamicfields/layouts" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Layout A",
    "description": "Layout A description",
    "subject_type": "asset",
    "object_type": "contract",
    "industry_ids": [
      "1f57219a-c836-4077-aeb6-8b2adaf56971"
    ],
    "is_default": true,
    "cards": [{
      "title": "Card title within the layout",
      "description": "This is the description of the card, and is used as text in the card.",
      "items": [{
        "item_type": "field",
        "field_id": "c0e409b0-2245-43fd-acb6-d60d3664b31b",
        "field": {
          "label": "This is a field label if item_type is field",
          "description": "This is the help text for the field",
          "field_type": "text",
          "config": {
            "max": 150,
            "multiline": true
          }
        }
      }]
    }],
    "updated_at": "2022-01-01T12:35:00.000Z"
  }]
}

This endpoint retrieves a result set of layouts, with any given filters applied.

Special note on for_asset_id: When this is invoked, the fields will automatically be appended to the return query for efficiency, otherwise, you will have to fetch the fields in a subsequent query. The reason for this is for efficiency (since invoking for_asset_id is likely because you're looking to display a layout), and avoiding large return payloads—the most for_asset_id will ever return is 2—the default, the the custom for that industry.

HTTP Request

GET https://<api-url>/dynamicfields/layouts

Query Parameters

asset contract service party

Parameter	Default	Description
ids[]	null	Filter results by these layout IDs
for_asset_id	null	For automatically returning the layouts pertaining to industries belonging to the entities of this asset id
object_type	null	Required: the object type, currently either `asset`, `contract`, `service`, or `party`.

CREATE a layout

curl -X POST "https://<api-url>/dynamicfields/layouts" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Layout A",
    "description": "Layout A description",
    "subject_type": "asset",
    "object_type": "contract",
    "industry_ids": [
      "1f57219a-c836-4077-aeb6-8b2adaf56971"
    ],
    "is_default": false,
    "cards": [{
      "title": "Card title within the layout",
      "description": "This is the description of the card, and is used as text in the card.",
      "items": [{
        "item_type": "field",
        "field_id": "c0e409b0-2245-43fd-acb6-d60d3664b31b"
      }]
    }]
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Layout A",
    "description": "Layout A description",
    "subject_type": "asset",
    "object_type": "contract",
    "industry_ids": [
      "1f57219a-c836-4077-aeb6-8b2adaf56971"
    ],
    "is_default": false,
    "cards": [{
      "title": "Card title within the layout",
      "description": "This is the description of the card, and is used as text in the card.",
      "items": [{
        "item_type": "field",
        "field_id": "c0e409b0-2245-43fd-acb6-d60d3664b31b"
      }]
    }]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an entity with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/dynamicfields/layouts

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
subject_id	enum	Only `asset` allowed at this point	No
object_id	enum	One of `asset`, `contract`, `service`, or `party`	No
industry_ids	uuid[]	Valid industry ID Industry	No
is_default	bool	MUST be `false`, since `true`s are controlled by the system	No
cards	obj	See 'cards' below	No

Cards

Attribute	Type	Restrictions	Null allowed
title	string	Max length 150	No
description	string	Max length 5000	No
items	obj	See 'items' below	No

Items

Attribute	Type	Restrictions	Null allowed
item_type	enum	Either `field` (in which field is required), or one of the predefined `item_types`	No
field_id	uuid	Valid v4 UUID, field must exist	Yes, if `item_type` is not `field`.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eFieldNotFound`	One of the field IDs given do not exist
400 BAD REQUEST	`eFieldObjectTypeMismatch`	The field ID given is for a different object type.
400 BAD REQUEST	`eIndustriesAlreadyAssigned`	You're assigning industries to a layout that already are assigned to another layout.

UPDATE a layout

curl -X PUT "https://<api-url>/dynamicfields/layouts/05e4b9a3-3f84-4fe0-a7ba-5e60ff9fea69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Layout A",
    "description": "Layout A description",
    "subject_type": "asset",
    "object_type": "contract",
    "industry_ids": [
      "1f57219a-c836-4077-aeb6-8b2adaf56971"
    ],
    "is_default": false,
    "cards": [{
      "title": "Card title within the layout",
      "description": "This is the description of the card, and is used as text in the card.",
      "items": [{
        "item_type": "field",
        "field_id": "c0e409b0-2245-43fd-acb6-d60d3664b31b"
      }]
    }]
  }'

A valid response will be a 200 OK, with the created object in the data atttribute

{
  "data": {
    "id": "05e4b9a3-3f84-4fe0-a7ba-5e60ff9fea69",
    "name": "Layout A",
    "description": "Layout A description",
    "subject_type": "asset",
    "object_type": "contract",
    "industry_ids": [
      "1f57219a-c836-4077-aeb6-8b2adaf56971"
    ],
    "is_default": false,
    "cards": [{
      "title": "Card title within the layout",
      "description": "This is the description of the card, and is used as text in the card.",
      "items": [{
        "item_type": "field",
        "field_id": "c0e409b0-2245-43fd-acb6-d60d3664b31b"
      }]
    }]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an entity with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

Default Layouts

Note, you can edit default layouts even though these are system layouts. This is so you can create a default that is relevant to your use case.

However, there are some extra rules. In addition to not being able to create default layouts, you cannot change the status of a default layout. You cannot update is_default to a value different than it already has. Ie, you cannot make a non-default layout default, or vice-versa.

HTTP Request

PUT https://<api-url>/dynamicfields/layouts/<id>

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
subject_id	enum	Only `asset` allowed at this point	No
object_id	enum	One of `asset`, `contract`, `service`, or `party`	No
industry_ids	uuid[]	Valid industry ID Industry	No
is_default	bool	MUST be `false`, since `true`s are controlled by the system	No
cards	obj	See 'cards' below	No

Cards

Attribute	Type	Restrictions	Null allowed
title	string	Max length 150	No
description	string	Max length 5000	No
items	obj	See 'items' below	No

Items

Attribute	Type	Restrictions	Null allowed
item_type	enum	Either `field` (in which field is required), or one of the predefined `item_types`	No
field_id	uuid	Valid v4 UUID, field must exist	Yes, if `item_type` is not `field`.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eLayoutNotFound`	Layout does not exist
400 BAD REQUEST	`eAttemptDeactivateDefaultLayout`	You cannot archive the default layout
400 BAD REQUEST	`eFieldNotFound`	One of the field IDs given do not exist
400 BAD REQUEST	`eFieldObjectTypeMismatch`	The field ID given is for a different object type.
400 BAD REQUEST	`eIndustriesAlreadyAssigned`	You're assigning industries to a layout that already are assigned to another layout.

DELETE a layout

curl -X DELETE "https://<api-url>/dynamicfields/layouts/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given layout by id.

HTTP Request

DELETE https://<api-url>/dynamicfields/layouts/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eLayoutNotFound`	The layout could not be found / invalid ID.
400 BAD REQUEST	`AttemptDeactivateDefaultLayout`	You cannot delete or archive a default layout.

LIST fields

curl "https://<api-url>/dynamicfields/fields" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "label": "Field A",
    "description": "Field A description",
    "field_type": "text",
    "config": {
      "max": 150,
      "multiline": true
    },
    "archived_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }]
}

This endpoint retrieves a result set of fields, with any given filters applied.

HTTP Request

GET https://<api-url>/dynamicfields/fields

Query Parameters

Parameter	Default	Description
object_type	enum	Must be one of the valid object types
ids[]	null	Filter results by these field IDs
field_type_in	string[]	Filter results by those of these field types
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
counts	Includes all items associated with this entity. Includes assets, contracts, datazones, and operational groups.

Sorting fields

Field	Description
label	Sort by label.

CREATE a field

curl -X POST "https://<api-url>/dynamicfields/fields" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "label": "Field A",
    "description": "Field A description",
    "field_type": "text",
    "config": {
      "max": 150,
      "multiline": true
    },
    "archived_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "label": "Field A",
    "description": "Field A description",
    "field_type": "text",
    "config": {
      "max": 150,
      "multiline": true
    },
    "archived_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a field with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/dynamicfields/fields

Parameters

Attribute	Type	Restrictions	Null allowed
label	string	Max length 150	No
description	string	Max length 5000	No
field_type	enum	One of the accepted field types	No
config	obj	Follow specific object config patterns for each field type	No
archived_at	datetime	When set to not-null, will archive the field	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details

UPDATE a field

curl -X PUT "https://<api-url>/dynamicfields/fields/8f768eb4-7d9a-48de-87e1-6aff65c65355" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "label": "Field A",
    "description": "Field A description",
    "field_type": "text",
    "config": {
      "max": 150,
      "multiline": true
    },
    "archived_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }'

A valid response will be a 200 OK, with the created object in the data atttribute

{
  "data": {
    "id": "8f768eb4-7d9a-48de-87e1-6aff65c65355",
    "label": "Field A",
    "description": "Field A description",
    "field_type": "text",
    "config": {
      "max": 150,
      "multiline": true
    },
    "archived_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a field with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

PUT https://<api-url>/dynamicfields/fields/<id>

Parameters

Attribute	Type	Restrictions	Null allowed
label	string	Max length 150	No
description	string	Max length 5000	No
field_type	enum	One of the accepted field types	No
config	obj	Follow specific object config patterns for each field type	No
archived_at	datetime	When set to not-null, will archive the field	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eFieldNotFound`	The field ID could not be found.

DELETE a field

curl -X DELETE "https://<api-url>/dynamicfields/fields/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given field by id.

HTTP Request

DELETE https://<api-url>/dynamicfields/fields/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eFieldNotFound`	The field could not be found / invalid ID.

LIST VALUES for a field

curl "https://<api-url>/dynamicfields/8e0f909d-6084-4276-be16-9fe2d7e0117f/values" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "field_id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "subject_type": "asset",
    "object_type": "contract",
    "object_id": "7863f96f-b6ae-4bf0-95b4-5881c745208b",
    "subject_id": "8e0f909d-6084-4276-be16-9fe2d7e0117f",
    "value": "Field value for subject/object",
    "updated_by": "75e386d3-af45-463f-9137-fad5c52e9889",
    "updated_at": "2022-01-01T12:35:00.000Z"
  }]
}

This endpoint retrieves a result set of fields, with any given filters applied.

HTTP Request

GET https://<api-url>/dynamicfields/<subjectId>/values

Query Parameters

Parameter	Default	Description
subject_type	enum	Must be one of the valid subject types
object_type	enum	Must be one of the valid object types
field_ids[]	null	Filter results by these field IDs
object_ids[]	null	Filter results by these object IDs

SET VALUES for a field

curl -X POST "https://<api-url>/dynamicfields/values" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "values": [{
      "label": "Field A",
      "description": "Field A description",
      "field_type": "text",
      "config": {
        "max": 150,
        "multiline": true
      },
      "archived_at": null,
      "created_at": "2022-01-01T12:35:00.000Z",
      "updated_at": "2022-01-01T12:35:00.000Z"
    }]
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": [{
    "object_type": "contract",
    "subject_type": "asset",
    "subject_id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "object_id": "8b393765-dd82-4538-be28-93f4a9e77c77",
    "value": "Field value for this subject/object combination."
  }],
  "warnings": [
    "Some error due to one of the items in the payload"
  ]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will assign values to the given fields. Note, you can assign values to multiple fields at once.

NOTE The subject IDs in the values MUST match that in your URI.

NOTE2 Due to the bulk nature of this request, individual validation errors and warnings will be given with the warnings output array. Regardless, I would rely on UI validation first and paramount.

HTTP Request

POST https://<api-url>/dynamicfields/values

Parameters

Attribute	Type	Restrictions	Null allowed
object_type	enum	Valid object type	No
subject_type	enum	Valid subject type	No
field_id	UUID	Valid field type	No
subject_id	UUID	Must match the UUID in the URI	No
object_id	UUID	Must exist (will use object type to look it up)	No
value	mixed	The value of the field. It will be validated against the field ID type.	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eFieldNotFound`	One or more of the fields given do not exist.

Entities

NOTE Section still under development - new fields and endpoints will be added as time goes on

Methods for dealing with the Entity object in the system.

Entities are organizations, bodies, or legal entities in the system that can be configured with different types. This new name is to replace the existing resource type in the system, which was poorly descriptive.

LIST Entities

curl "https://<api-url>/entities" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Entity A",
    "description": "Entity A description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "stats": [{
      "assets": 2,
      "contracts": 5,
      "datazones": 6,
      "operational": 2
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "entities.view",
      "entities.update"
    ]
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Account Entity B",
    "description": null,
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": null,
    "phone": null,
    "url": null,
    "stats": [{
      "assets": 0,
      "contracts": 0,
      "datazones": 0,
      "operational": 0
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "entities.view"
    ]
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }]
}

This endpoint retrieves a result set of enitites, with any given filters applied.

HTTP Request

GET https://<api-url>/entities

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these entity IDs
keywords	null	Filter results by the given keywords. Keywords search across `name`.
include[]	null	Include extra embeded non-resource elements (See list below)
type_id	null	Filter results for entities with this type ID (see types from entity type endpoint)
contract_id	null	Filter results for those associated with this contract ID
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
counts	Includes all items associated with this entity. Includes assets, contracts, datazones, and operational groups.

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
type	Sort by type
total_contracts	Sort by total contracts
total_assets	Sort by total assets
total_datazones	Sort by total datazones
total_operational_groups	Sort by total operational groups
created	Sort by create date
updated	Sort by update date

LIST Entity Types

These are types for the entities. See Entity Type

curl "https://<api-url>/entities/~/types" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "External client",
    "description": "Some description",
    "base_type": "client",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Internal client",
    "description": "Some description",
    "base_type": "client",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of entity types. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

Base Types define the behaviour of this type in the system. See Entity Type object for a description of the base types.

HTTP Request

GET https://<api-url>/entities/~/types

LIST Entity Roles

These are role associations for the entities contacts and owners. See Entity Role Type

curl "https://<api-url>/entities/~/roles" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Customer Success",
    "description": "Some description",
    "type": "owner",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Primary Contact",
    "description": "Some description",
    "type": "contact",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of entity roles. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

You can also filter this result by type.

HTTP Request

GET https://<api-url>/entities/~/roles

Query Parameters

Parameter	Default	Description
type	null	Filter results for only given role types. Valid entries are `contact` or `owner`.

GET an Entity

curl "https://<api-url>/entities/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Entity A",
    "description": "Entity A description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "3f24a0f4-6c83-49bd-81ba-c0d7a13bfa1c"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "4e50a5f8-e1e7-4c1d-827c-7ac328f8bab3"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "896e1914-2738-43ef-b15e-a88070e22245"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "4a7225f3-0b86-4430-937e-51b331b131d8"
    }],
    "service_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null,
    "__permissions__": [
      "entities.view",
      "entities.update"
    ]
  }
}

In the case that no entity is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific entity by the given id.

HTTP Request

GET https://<api-url>/entities/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the entity to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eEntityNotFound`	The entity could not be found / invalid ID.

CREATE a new Entity

curl -X POST "https://<api-url>/entities" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "A created Entity",
    "description": "Created Entity description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "service_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created Entity",
    "description": "Created Entity description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "service_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "entities.view",
      "entities.create",
      "entities.update"
    ]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an entity with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/entities

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type_id	uuid	Valid entity type ID Entity Type	Yes
industry_id	uuid	Valid industry ID Industry	Yes
phone	string	Valid e164 number format	Yes
url	string	Max length 1000	Yes
addresses	Address[]	Use empty array for none	No
owners	PartyAssociation[]	Use empty array for empty	No
contacts	PartyAssociation[]	Use empty array for empty	No
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eEntityTypeNotFound`	Entity type ID given could not be found
400 BAD REQUEST	`eAttemptSaveWithMissingIndustries`	The industry ID you've given could not be found
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	One or more of the service ids you've given do not exist.
400 BAD REQUEST	`eAttemptSaveWithMissingRoles`	Some of the role ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingContacts`	Some or all of the contacts ids you've given do not exist

UPDATE an Entity

curl -X PUT "https://<api-url>/entities/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "An updated Entity",
    "description": "Updated Entity description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "service_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "An updated Entity",
    "description": "Updated Entity description",
    "type_id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "industry_id": "deadc0de-9c89-4812-af13-8f3f8bcc4ca5",
    "phone": "+17785551122",
    "url": "https://google.com/boop",
    "service_ids": [
      "deadc0de-2222-4849-a096-5800072f28c2",
      "deadc0de-2222-4b26-89eb-4ed6de8baa53"
    ],
    "owners": [{
      "id": "deadc0de-3333-4849-a096-5800072f28c2",
      "role_id": "deadc0de-d372-477d-8544-8eed6511427f"
    }, {
      "id": "deadc0de-3333-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-5af6-40bd-9118-401f5bc03c89"
    }],
    "contacts": [{
      "id": "deadc0de-4444-4849-a096-5800072f28c2",
      "role_id": "deadc0de-44b6-4ab9-bb57-9175396a59aa"
    }, {
      "id": "deadc0de-4444-4b26-89eb-4ed6de8baa53",
      "role_id": "deadc0de-40b3-4379-a8b6-d44149e18586"
    }],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z",
    "__permissions__": [
      "entities.view",
      "entities.update"
    ]
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing entity with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/entities/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the entity to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type_id	uuid	Valid entity type ID Entity Type	Yes
industry_id	uuid	Valid industry ID Industry	Yes
phone	string	Valid e164 number format	Yes
url	string	Max length 1000	Yes
addresses	Address[]	Use empty array for none	No
owners	PartyAssociation[]	Use empty array for empty	No
contacts	PartyAssociation[]	Use empty array for empty	No
service_ids	uuid[]	Valid service ids. Use empty array for empty.	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eEntityNotFound`	Entity ID given could not be found
400 BAD REQUEST	`eEntityTypeNotFound`	Entity type ID given could not be found
400 BAD REQUEST	`eAttemptSaveWithMissingIndustries`	The industry ID you've given could not be found
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	One or more of the service ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingRoles`	Some of the role ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist
400 BAD REQUEST	`eAttemptSaveWithMissingContacts`	Some or all of the contacts ids you've given do not exist

BATCH UPDATE Entities

curl -X PATCH "https://<api-url>/entities" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
      "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
      "suspended_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "service_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
    "service_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
    "suspended_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch Entity fields. To help maintain the integrity of Entity, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The contract & service ID fields will allow assigning and unassigning contracts and services from the given entity. Note, only one can be given at a time for each entity.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/entities

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
contract_id_assign	uuid	None	Yes, but will no-op
contract_id_unassign	uuid	None	Yes, but will no-op
service_id_assign	uuid	None	Yes, but will no-op
service_id_unassign	uuid	None	Yes, but with no-op
suspended_at	datetime	Will de-activate (suspend) the entity if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the entity if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' entities endpoint.

BATCH Assign Contract to Entities

curl -X PATCH "https://<api-url>/entities/~/actions/assign_contract" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "contract_id": "dba81a06-4985-491a-8d64-d39898477b28",
    "push": [
      "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "e3d53daf-87d4-4427-a215-000cce6d0f99"
    ],
    "pull: [
      "aa122ac3-54b0-4b90-93cd-d32e907980c8"
    ]
  }'

A valid response will be a 204 NO CONTENT. In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the one-time adding/removing a single contract to and from multiple entity IDs. This is not a standard REST endpoint, but a convenience one to ensure efficient API usage.

HTTP Request

POST https://<api-url>/entities/~/actions/assign_contract

Paramaters

Attribute	Type	Restrictions	Null allowed	Description
contract_id	uuid	Required	No	The contract to batch add/remove from the entities
push	uuid[]	Required	No	All the entity IDs to add this `contract_id` to
pull	uuid[]	Required	No	All the entity IDs to remove this `contract_id` from

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eEntitiesNotFound`	Some of the given entities could not be found. See message for ids.
400 BAD REQUEST	`eAttemptSaveWithMissingContracts`	The contract ID given could not be found.

BATCH Assign Service to Entities

curl -X PATCH "https://<api-url>/entities/~/actions/assign_service" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "service_id": "dba81a06-4985-491a-8d64-d39898477b28",
    "push": [
      "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "e3d53daf-87d4-4427-a215-000cce6d0f99"
    ],
    "pull: [
      "aa122ac3-54b0-4b90-93cd-d32e907980c8"
    ]
  }'

A valid response will be a 204 NO CONTENT. In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the one-time adding/removing a single service to and from multiple entity IDs. This is not a standard REST endpoint, but a convenience one to ensure efficient API usage.

HTTP Request

POST https://<api-url>/entities/~/actions/assign_service

Paramaters

Attribute	Type	Restrictions	Null allowed	Description
service_id	uuid	Required	No	The service to batch add/remove from the entities
push	uuid[]	Required	No	All the entity IDs to add this `service_id` to
pull	uuid[]	Required	No	All the entity IDs to remove this `service_id` from

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eEntitiesNotFound`	Some of the given entities could not be found. See message for ids.
400 BAD REQUEST	`eAttemptSaveWithMissingServices`	The service ID given could not be found.

DELETE an Entity

curl -X DELETE "https://<api-url>/entities/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given entity by id.

HTTP Request

DELETE https://<api-url>/entities/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eEntityNotFound`	The entity could not be found / invalid ID.

Features

NOTE Section still under development - new fields and endpoints will be added as time goes on

Methods for dealing with the Feature object in the system. There are two noteworthy fields on each feature set:

permission

This is a tag used by the system to denote the actual ability that this feature allows. Currently, only one is accepted, but with plans to permit multiples in the future.

is_system

This is whether the feature is a system feature or not. System features are delivered on provisioning, and cannot be edited or deleted.

Note on development

Currently, this endpoint is slowly migrating the existing "features" functionality in the system.

LIST features

curl "https://<api-url>/features" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Feature A",
    "permission": "contracts.view",
    "is_system": true,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Feature B",
    "permission": "contracts.update",
    "is_system": true,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }]
}

This endpoint retrieves a result set of features, with any given filters applied.

HTTP Request

GET https://<api-url>/features

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these feature IDs
keywords	null	Filter results by the given keywords. Keywords search across `name`.
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Sorting fields

Field	Description
name	Sort by name.
created	Sort by create date
updated	Sort by update date

LIST Feature Categories

These are categories for the features. See Feature Category

The sys_name field allows for two things. First, it identifies a category as a system category and thus cannot be deleted or modified. Also, it gives a static 'tag' for the field, so appropriate vocabulary renaming can be done for the client.

curl "https://<api-url>/features/~/categories" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Service",
    "sys_name": "service",
    "parent_id": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Dashboard",
    "sys_name": "dashboard",
    "parent_id": "abfe045b-814e-4d31-98f5-f3d0a23437f1"
  }]
}

This endpoint retrieves a result set of feature categories. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

HTTP Request

GET https://<api-url>/features/~/categories

GET a Feature

curl "https://<api-url>/features/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Feature A",
    "permission": "contracts.view",
    "is_system": true,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case that no feature is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific feature by the given id.

HTTP Request

GET https://<api-url>/features/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the feature to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eFeatureNotFound`	The feature could not be found / invalid ID.

Groups

Methods for dealing with the Group object in the system.

Groups in the system have 4 possible base types (See Group Types)

User
Territory
Feature
Operational

The first three, are groups containing their self-described subjects. The forth -- the "operational" group -- contains a collection of the former three. These provide functionality to the users for the included features and territories.

In the groups response, the following hard rules are applied:

Only operational groups may have a combination of different group types in it's "inherited" groups. All other groups may only inherit the same time.
Only operational groups may inherit from operational groups3. The data array is context specific to the base group type
Groups without supplementary data may have their meta attribute set to null, if they do not have any additional data.

How groups are structured

Groups Examples

Differences between list resource and single resource

In the interest of performance and scaling, the resource representation in the list response is shortened compared to the full resource response as seen in the "single" get, post, and put responses.

Items that do not exist on the list response include:

items
owner_ids
inherit_ids

System Groups

Some groups are considered "system" groups. At the time of writing, only features may have system groups. These are groups that are set on client creation, and cannot be edited or deleted. These groups convey a base functionality that exist in every client.

The attribute for system groups is is_system.

Group Items

Item IDs are items the group contains. The following group types are paired with the accepted items:

Group Type	Item Type	Notes
`user`	`party` of type `user`	These are currently what we call 'users' in the system
`feature`	`features`
`territories`	`datazones`
`operational`	None	The `items` array is ignored.

Item lists, inherited group lists, and counts

All group and item lists are those directly relating to the given group. Count stats are aggregates from of all items of this group, and all groups it recursively inherits from.

When fetching and editing groups, items and inherit_ids are a list of UUIDs.

Note, saving the group requires an array of UUIDs only for items and inherit_ids. This operation does not accept full objects.

LIST Groups

curl "https://<api-url>/groups" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "North America",
    "type": "territory",
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "stats": [{
      "territory": 14,
      "user": 0,
      "feature": 0,
      "inherits": 4
    }],
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Operational Group 1",
    "type": "operational",
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "stats": [{
      "territory": 2,
      "user": 3,
      "feature": 31,
      "inherits": 4
    }],
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "items": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }]
}

This endpoint retrieves a resultset of groups, with any given filters applied.

By default, this payload only includes the items directly associated with the group. Inherited groups are not given.

HTTP Request

GET https://<api-url>/groups

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these contract IDs
type	null	Filter results by the given type ID
keywords	null	Filter results by the given keywords. Keywords search across `name` and `description`. Min characters 2.
party_id	null	Filter results for those associated with this party ID
entity_id	null	Filter results by groups that are associated with this entity ID. This is a recursive filter, and will includes all inherited groups too.
datazone_id	null	Filter results by only those containing the given datazone (will return only territory groups)
include[]	null	Include extra embeded non-resource elements (See list below)
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
counts	Includes object count totals, such as all users, datazones, features, and inherited groups. Note this is a total of all inherited too.

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
total_user	Sort by total user count
total_datazone	Sort by total datazone count
total_feature	Sort by total feature count
total_inherited	Sort by total inherited count
created	Sort by create date
updated	Sort by update date

Note, sorting on individual object counts will come at a future time

GET a Group

curl "https://<api-url>/groups/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Sales Group A",
    "type": "operational",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "inherit_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],,
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

An expanded result will include all the sub objects and their counts.

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Sales Group A",
    "type": "operational",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "inherit_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "stats": [{
      "territory": 2,
      "user": 3,
      "feature": 31,
      "inherits": 5
    }],
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case that no group is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific group by the given id.

HTTP Request

GET https://<api-url>/groups/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the group to retrieve
include[]	null	Include extra embeded non-resource elements.

Embed/Include Parameters

Option	Description
counts	Includes object count totals, such as all users, datazones, features, and inherited groups. Note this is a total of all inherited too.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eGroupNotFound`	The group could not be found / invalid ID.

CREATE a new Group

curl -X POST "https://<api-url>/groups" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "North America",
    "type": "user",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "inherit_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
      "cfedec18-339e-4570-a971-4b1e9d1f811a"
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],,
    "meta": {
      "email": "communications@gmail.com"
    },
    "suspended_at": null
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "North America",
    "type": "user",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "inherit_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
      "cfedec18-339e-4570-a971-4b1e9d1f811a"
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],,
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will create a group with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/groups

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type	Group Type	One of the valid types	No
owner_ids	uuid[]	Valid party IDs (can also use legacy user ids)
inherit_ids	uuid[]	Valid group IDs	No, use empty array
items	array of uuids	Valid IDs for this group type if not operational.	No
meta	Key/Value[]	As per key/value type	Yes
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAttemptGroupTypeChange`	You cannot change the group type once created.
400 BAD REQUEST	`eAttemptSaveWithMissingInherits`	One or more of the inherit_ids you've given do not exist.
400 BAD REQUEST	`eAttemptNonOperationalOtherTypeInherit`	You tried to mix group types in the inherit array for a non-operational type.
400 BAD REQUEST	`eAttemptSaveWithMissingItems`	Some of the item ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist

UPDATE a Group

curl -X PUT "https://<api-url>/groups/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "North America",
    "type": "user",
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "inherit_id": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
      "cfedec18-339e-4570-a971-4b1e9d1f811a"
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "meta": {
      "email": "communications@gmail.com"
    },
    "suspended_at": null
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "3823424f-dcc3-40b1-82e5-d71b0a194c69",
    "name": "North America",
    "type": "user",
    "owner_ids": [
      "d76273ac-a300-469f-9d88-14c44de1ad6b"
    ],
    "description": "Lorem ipsum dolor sit amet, consectetur...",
    "inherit_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1",
      "cfedec18-339e-4570-a971-4b1e9d1f811a"
    ],
    "items": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "meta": {
      "email": "communications@gmail.com"
    },
    "is_system": false,
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing group with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/groups/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the group to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
type	Group Type	One of the valid types	No
owner_ids	uuid[]	Valid party IDs (can also use legacy user ids)
inherit_ids	uuid[]	Valid group IDs	No, use empty array
items	array of uuids	Valid IDs for this group type if not operational.	No
meta	Key/Value[]	As per key/value type	Yes
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eGroupNotFound`	The group could not be found / invalid ID.
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eAttemptGroupTypeChange`	You cannot change the group type once created.
400 BAD REQUEST	`eAttemptSaveWithMissingInherits`	One or more of the inherit_ids you've given do not exist.
400 BAD REQUEST	`eAttemptNonOperationalOtherTypeInherit`	You tried to mix group types in the inherit array for a non-operational type.
400 BAD REQUEST	`eAttemptSaveWithMissingItems`	Some of the item ids you've given were missing
400 BAD REQUEST	`eAttemptSaveWithMissingOwners`	Some or all of the owner ids you've given do not exist

BATCH UPDATE Groups

curl -X PATCH "https://<api-url>/groups" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "owner_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
      "owner_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
      "item_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
      "item_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
      "suspended_at": null,
      "deleted_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "owner_id_assign": "b9a34a93-f003-4a48-b8a0-bd932762f814",
    "owner_id_unassign": "ac9eef4d-5205-4b3c-b1a9-4a5d2f447ecd",
    "item_id_assign": "cc561e38-f782-4a48-946f-1a0b28a8b10c",
    "item_id_unassign": "4253e456-6f8f-4025-b133-e757f0cc866e",
    "suspended_at": null,
    "deleted_at": null
  }]
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch group fields. To help maintain the integrity of groups, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/groups

Accepted PATCH Parameters within 'data' array

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
owner_id_assign	uuid	None	Yes, but will no-op
owner_id_unassign	uuid	None	Yes, but will no-op
item_id_assign	uuid	None	Yes, but will no-op
item_id_unassign	uuid	None	Yes, but with no-op
suspended_at	datetime	Will de-activate (suspend) the group if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the group if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' group endpoint.

BATCH Assign Item to Groups

curl -X PATCH "https://<api-url>/groups/~/actions/assign_item" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "item_id": "dba81a06-4985-491a-8d64-d39898477b28",
    "push": [
      "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "e3d53daf-87d4-4427-a215-000cce6d0f99"
    ],
    "pull: [
      "aa122ac3-54b0-4b90-93cd-d32e907980c8"
    ]
  }'

A valid response will be a 204 NO CONTENT. In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the one-time adding/removing a single item to and from multiple group IDs. This is not a standard REST endpoint, but a convenience one to ensure efficient API usage.

HTTP Request

POST https://<api-url>/groups/~/actions/assign_item

Paramaters

Attribute	Type	Restrictions	Null allowed	Description
item_id	uuid	Required	No	The item to batch add/remove from the groups
push	uuid[]	Required	No	All the group IDs to add this `item_id` to
pull	uuid[]	Required	No	All the group IDs to remove this `item_id` from

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eGroupsNotFound`	Some of the given groups could not be found. See message for ids.
400 BAD REQUEST	`eItemUpdateWithVaryingGroupTypes`	Some of the groups in your arrays have differing group types. All groups must be the same type.
400 BAD REQUEST	`eAttemptSaveWithMissingItems`	The item ID given could not be found. Please ensure the item is the correct type for the groups given.

BATCH Assign an Owner to Groups

curl -X PATCH "https://<api-url>/groups/~/actions/assign_owner" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "party_id": "dba81a06-4985-491a-8d64-d39898477b28",
    "push": [
      "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "e3d53daf-87d4-4427-a215-000cce6d0f99"
    ],
    "pull: [
      "aa122ac3-54b0-4b90-93cd-d32e907980c8"
    ]
  }'

A valid response will be a 204 NO CONTENT. In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the one-time adding/removing a single party owner to and from multiple group IDs. This is not a standard REST endpoint, but a convenience one to ensure efficient API usage.

HTTP Request

POST https://<api-url>/groups/~/actions/assign_owner

Paramaters

Attribute	Type	Restrictions	Null allowed	Description
party_id	uuid	Required	No	The party to batch add/remove as an owner from the groups
push	uuid[]	Required	No	All the group IDs to add this `party_id` owner to
pull	uuid[]	Required	No	All the group IDs to remove this `party_id` owner from

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eGroupsNotFound`	Some of the given groups could not be found. See message for ids.
400 BAD REQUEST	`ePartyNotFound`	The party ID given could not be found.

DELETE a Group

curl -X DELETE "https://<api-url>/groups/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given group by id.

Note, this group will be deleted. Any groups inheriting from it will not be affected directly, only losing their inherited properties

HTTP Request

DELETE https://<api-url>/groups/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eGroupNotFound`	The group could not be found / invalid ID.

Heatmaps

Methods for dealing with Heatmap configuration object in the system.

These are effective individual heatmap configurations. Once executed, they generate a heatmap result.

LIST Heatmaps

curl "https://<api-url>/heatmaps" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "deadc0de-1111-4b7a-a990-111111111111",
    "name": "Heatmap A",
    "description": "Heatmap A description",
    "type": "business",
    "stats": [{
      "groups.operational": 7,
      "groups.user": 4
    }],
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null
  }, {
    "id": "deadc0de-2222-4b7a-a990-222222222222",
    "name": "Heatmap B",
    "description": "Heatmap B description",
    "type": "system",
    "stats": [{
      "groups.operational": 0,
      "groups.user": 0
    }],
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "total": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of heatmaps, with any given filters applied.

HTTP Request

GET https://<api-url>/heatmaps

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these heatmap IDs
keywords	null	Filter results by the given keywords. Keywords search across `name` and `description`.
include[]	null	Include extra embeded non-resource elements (See list below)
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Include Parameters

Option	Description
stats	Includes object stats. This includes total contracts and services at this point.

Sorting fields

Field	Description
name	Sort by name
description	Sort by description
type	Sort by type
total_user_groups	Sort by total user group count
total_op_groups	Sort by total operational group count
created	Sort by create date
updated	Sort by update date

GET a Heatmap

curl "https://<api-url>/heatmap/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "deadc0de-1111-4b7a-a990-111111111111",
    "name": "Heatmap A",
    "description": "Heatmap A description",
    "type": "business",
    "owner_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1"
    ],
    "group_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "metrics": [{
      "field_id": null,
      "label": "Total count",
      "ref": "number",
      "calc": "sum",
      "ranges": null
    }, {
      "field_id": "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0",
      "label": "Total Sq Floor floor area",
      "ref": "size",
      "calc": "avg",
      "ranges": [0, 24, 50, 75, 100]
    }, {
      "field_id": "cdab8d4f-4498-4165-9be2-aabf0ae05f7b",
      "label": "Some label for this field",
      "ref": "color",
      "calc": "max",
      "ranges": [0, 50, 100]
    }, {
      "field_id": "b59b2f68-a736-47e4-a2e8-4b8d259942c9",
      "label": "Some label",
      "ref": "shadow",
      "calc": "max",
      "ranges": [0, 10, 30, 100]
    }],
    "stats": [{
      "groups.operational": 7,
      "groups.user": 4
    }],
    "suspended_at": null,
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null
  }
}

In the case that no heatmap is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific heatmap by the given id.

HTTP Request

GET https://<api-url>/heatmap/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the heatmap to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eHeatmapNotFound`	The heatmap could not be found / invalid ID.

CREATE a new Heatmap

curl -X POST "https://<api-url>/heatmap" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Created Heatmap",
    "description": "Created Heatmap Description",
    "type": "business",
    "owner_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1"
    ],
    "group_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "metrics": [{
      "field_id": null,
      "label": "Total count",
      "ref": "number",
      "calc": "sum",
      "ranges": null
    }, {
      "field_id": "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0",
      "label": "Total Sq Floor floor area",
      "ref": "size",
      "calc": "avg",
      "ranges": [0, 24, 50, 75, 100]
    }, {
      "field_id": "cdab8d4f-4498-4165-9be2-aabf0ae05f7b",
      "label": "Some label for this field",
      "ref": "color",
      "calc": "max",
      "ranges": [0, 50, 100]
    }, {
      "field_id": "b59b2f68-a736-47e4-a2e8-4b8d259942c9",
      "label": "Some label",
      "ref": "shadow",
      "calc": "max",
      "ranges": [0, 10, 30, 100]
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Created Heatmap",
    "description": "Created Heatmap Description",
    "type": "business",
    "owner_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1"
    ],
    "group_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "metrics": [{
      "field_id": null,
      "label": "Total count",
      "ref": "number",
      "calc": "count",
      "ranges": null
    }, {
      "field_id": "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0",
      "label": "Total Sq Floor floor area",
      "ref": "size",
      "calc": "avg",
      "ranges": [0, 24, 50, 75, 100]
    }, {
      "field_id": "cdab8d4f-4498-4165-9be2-aabf0ae05f7b",
      "label": "Some label for this field",
      "ref": "color",
      "calc": "max",
      "ranges": [0, 50, 100]
    }, {
      "field_id": "b59b2f68-a736-47e4-a2e8-4b8d259942c9",
      "label": "Some label",
      "ref": "shadow",
      "calc": "max",
      "ranges": [0, 10, 30, 100]
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an heatmap with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/heatmaps

Parameters

Attribute	Type	Null allowed	Restrictions
name	string	No	The name of the heatman
description	string	Yes	Description for the heatmap
type	enum	No	Type of Heatmap, one of `system`, `business`, or `user`
owner_ids*	uuid[]	No	Valid party ids. Use empty array for empty.
group_ids*	uuid[]	No	Valid group ids. Use empty array for empty.
metrics	Heatmap Metric[]	No	Valid array of metrics to caculate
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eInvalidMetricField`	There was a problem with of the metric fields given
400 BAD REQUEST	`eGroupNotFound`	One of the groups given could not be found
400 BAD REQUEST	`eOwnerNotFound`	One of the owners given could not be found

UPDATE an Heatmap

curl -X PUT "https://<api-url>/heatmaps/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Updated Heatmap",
    "description": "Updated Heatmap Description",
    "type": "business",
    "owner_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1"
    ],
    "group_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "metrics": [{
      "field_id": null,
      "label": "Total count",
      "ref": "number",
      "calc": "sum",
      "ranges": null
    }, {
      "field_id": "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0",
      "label": "Total Sq Floor floor area",
      "ref": "size",
      "calc": "avg",
      "ranges": [0, 24, 50, 75, 100]
    }, {
      "field_id": "cdab8d4f-4498-4165-9be2-aabf0ae05f7b",
      "label": "Some label for this field",
      "ref": "color",
      "calc": "max",
      "ranges": [0, 50, 100]
    }, {
      "field_id": "b59b2f68-a736-47e4-a2e8-4b8d259942c9",
      "label": "Some label",
      "ref": "shadow",
      "calc": "max",
      "ranges": [0, 10, 30, 100]
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Updated Heatmap",
    "description": "Updated Heatmap Description",
    "type": "business",
    "owner_ids": [
      "fbe2c9e2-089c-4cf3-aaf9-ad56a4799c79",
      "cfedec18-339e-4570-a971-4b1e9d1f811a",
      "5ffd53c3-97ec-40fe-a73f-f95a83f31dc1"
    ],
    "group_ids": [
      "6ccad6a4-bbbd-4d3e-9f64-2132bee25a84",
      "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0"
    ],
    "metrics": [{
      "field_id": null,
      "label": "Total count",
      "ref": "number",
      "calc": "sum",
      "ranges": null
    }, {
      "field_id": "337cc5bf-5f74-4a0c-a0c3-bf1911611fb0",
      "label": "Total Sq Floor floor area",
      "ref": "size",
      "calc": "avg",
      "ranges": [0, 24, 50, 75, 100]
    }, {
      "field_id": "cdab8d4f-4498-4165-9be2-aabf0ae05f7b",
      "label": "Some label for this field",
      "ref": "color",
      "calc": "max",
      "ranges": [0, 50, 100]
    }, {
      "field_id": "b59b2f68-a736-47e4-a2e8-4b8d259942c9",
      "label": "Some label",
      "ref": "shadow",
      "calc": "max",
      "ranges": [0, 10, 30, 100]
    }],
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing heatmap with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/heatmaps/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the heatmap to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	No	The name of the heatman
description	string	Yes	Description for the heatmap
type	enum	No	Type of Heatmap, one of `system`, `business`, or `user`
owner_ids*	uuid[]	No	Valid party ids. Use empty array for empty.
group_ids*	uuid[]	No	Valid group ids. Use empty array for empty.
metrics	Heatmap Metric[]	No	Valid array of metrics to caculate
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eHeatmapNotFound`	The Heatmap with the ID given could not be found
400 BAD REQUEST	`eInvalidMetricField`	There was a problem with of the metric fields given
400 BAD REQUEST	`eGroupNotFound`	One of the groups given could not be found
400 BAD REQUEST	`eOwnerNotFound`	One of the owners given could not be found

DELETE a Heatmap

curl -X DELETE "https://<api-url>/heatmaps/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given heatmap by id.

HTTP Request

DELETE https://<api-url>/heatmaps/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eHeatmapNotFound`	The heatmap could not be found / invalid ID.

QUERY a Heatmap

curl "https://<api-url>/heatmaps/f24600bf-2ed4-489e-a838-83d66a022b27/query" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "zoom": 5,
    "bound": "POLYGON((40.000 100.000 52.1232 123.023))",
    "clusters": [{
      "datazone_id": "90983be0-31da-49db-8c72-46b80ce959d9",
      "pins": [{
        "lat": "48.34234234234",
        "long": "-101.3426234234",,
        "field": null,
        "count": "2",
        "metrics": [{
          "field_id": "f137e119-52b7-4411-a249-40c5f4ca1134",
          "label": "Total count",
          "ref": "number",
          "percent": "67",
          "total": "123151"
        }, {
          "field_id": "2426c56e-2c8a-411d-be40-30159b455836",
          "label": "Total Sq Floor floor area",
          "ref": "size",
          "percent": "23",
          "total": "324"
        }, {
          "field_id": "f081cd89-67a7-4a3b-a0c7-bd24d03321be",
          "label": "Some label for this field",
          "ref": "color",
          "percent": "100",
          "total": "214"
        }, {
          "field_id": "c1eb55d2-5aab-4cc9-b60e-b1e98999f1c9",
          "label": "Total count",
          "ref": "shadow",
          "percent": "10",
          "total": "12"
        }],
        "items": null
      }, {
        "lat": "51.11231",
        "long": "-95.992315",
        "field": null,
        "count": "1",
        "metrics": [{
          "field_id": "f137e119-52b7-4411-a249-40c5f4ca1134",
          "label": null,
          "ref": "number",
          "percent": "67",
          "total": "123151"
        }, {
          "field_id": "2426c56e-2c8a-411d-be40-30159b455836",
          "label": null,
          "ref": "size",
          "percent": "23",
          "total": "324"
        }, {
          "field_id": "f081cd89-67a7-4a3b-a0c7-bd24d03321be",
          "label": null,
          "ref": "color",
          "percent": "100",
          "total": "214"
        }, {
          "field_id": "c1eb55d2-5aab-4cc9-b60e-b1e98999f1c9",
          "label": null,
          "ref": "shadow",
          "percent": "10",
          "total": "12"
        }],
        "items": [
          "fad9e63f-4426-4caf-807e-def3681ef642"
        ]
      }]
    }, {
      "datazone_id": "e72401b3-8851-498d-8434-6c877b16a1ae",
      "pins": []
    }, {
      "datazone_id": null,
      "pins": []
    }]
  }],
  "warnings": []
}

This endpoint executes a heatmap query. It returns the results of the Heatmap Query Result

HTTP Request

GET https://<api-url>/heatmaps/f24600bf-2ed4-489e-a838-83d66a022b27/query

Query Parameters

Parameter	Default	Description
zoom*	n/a	Integer 0-16, Zoom level
bound*	n/a	String WKT. Bounding box for the operation. Default, send screen viewport.
keywords	''	String, Search terms for locations to heatmap against. Will be restricted to `bound`
group_type	`cluster``	Determines the grouping to do on all the datapoints.
types	[`asset`,`entity`]	Enum. Types to search against.
show_items_below_size	integer	Default 5. If the count of items in a cluster is below this size, given them in `items`
datazones	string[]	Constrain to these datazones
query	string	Mapping keyword query to run in conjuction with the bounding box
type	enum	On what to run the mapping query (*required if `query` given)

* Required fields

Datapoint grouping types

cluster
region
country
city

When cluster is the grouping type, then long and lat are completed. If any of the others are selected, then long and lat are null and field contains the grouping value.

TEMPORARY Query Parameters

These highly influence the way the clustering algorithm is used. Please use these to manipulate the results.

When we reach stablility, I will remove these query params and make these fields the default.
If there are any we want to keep, for customer configuration etc, we will then adjust so they remain a query parameter.
Please avoid changing node_size if possible, it affects performance.

Parameter	Default	Description (from the library docs)
min_cluster_size	2	Minimum number of points to form a cluster.
radius	40	Cluster radius, in pixels.
extent	512	(Tiles) Tile extent. Radius is calculated relative to this value.
node_size	64	Size of the KD-tree leaf node. Affects performance.

Note, the library we're using is here: https://www.npmjs.com/package/supercluster

Industries

Methods for dealing with the Industry object in the system.

Since this is a catalog endpoint, and is infrequently edited, there is no pagination or sorting. The whole result is returned. Sorting and filtering can be formed in-stu in the client.

LIST Industries

curl "https://<api-url>/industries" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Mining",
    "created_at": "2022-01-01T12:35:00.000Z",
    "archived_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Shipping",
    "created_at": "2022-01-01T12:35:00.000Z",
    "archived_at": null
  }],
  "warnings": []
}

This endpoint retrieves a result set of industries.

HTTP Request

GET https://<api-url>/industries

GET an Industry

curl "https://<api-url>/industries/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Mining",
    "created_at": "2022-01-01T12:35:00.000Z",
    "archived_at": null
  }
}

In the case that no industry is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific contract by the given id.

HTTP Request

GET https://<api-url>/industries/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the industry to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eIndustryNotFound`	The industry could not be found / invalid ID.

CREATE an Industry

curl -X POST "https://<api-url>/industries" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "A created Industry",
    "archived_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created Industry",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create an industry with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/industries

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
archived_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details

UPDATE an Industry

curl -X PUT "https://<api-url>/industries/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "An updated Industry",
    "archived_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "An updated Industry",
    "archived_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing industry with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/industries/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the industry to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
archived_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eIndustryNotFound`	Industry ID given could not be found

DELETE an Industry

curl -X DELETE "https://<api-url>/industries/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given industry by id.

HTTP Request

DELETE https://<api-url>/industries/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eIndustryNotFound`	The industry could not be found / invalid ID.

Job Titles

Methods for dealing with the Job Title object in the system.

Since this is a catalog endpoint, and is infrequently edited, there is no pagination or sorting. The whole result is returned. Sorting and filtering can be formed in-stu in the client.

LIST Job Titles

curl "https://<api-url>/jobtitles" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Manager",
    "created_at": "2022-01-01T12:35:00.000Z",
    "archived_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Trainee",
    "created_at": "2022-01-01T12:35:00.000Z",
    "archived_at": null
  }],
  "warnings": []
}

This endpoint retrieves a result set of job titles.

HTTP Request

GET https://<api-url>/jobtitles

Parties

NOTE Section still under development

Methods for dealing with the Party object in the system.

Parties are individuals, or "people" in the system. They are defined by a configurable type, which are split into two fundamenetal base types:

User
Contact

Identities

Identities are how a user logs into a service. They are decoupled from the actual user/person record themselves as standard practice. Even if the business logic only dictates a 1-1 relationship, having it 1-many will allow future changes if multiple login methods are required.

As an example, a single user could log-in with one or more of the following:

Work SSO Email
Personal Email
Mobile Phone Number
Username
Private/Public Key identification (ie, keytags)

All these are examples of identities. They would all correlate to the user/person record.

To meet the initial spec of Proximity, fix all users to one 'email' identity. Examples of identities are given here: PartyIdentity.

Profile

These are effectively custom profile fields for users/contacts. A list of currently accepted keys are given here: PartyProfile

Other base attributes such as "email" and "phone" may be moved into this format in the future.

Future plans, this profile is to follow the same format as system-wide custom fields.

LIST Parties

curl "https://<api-url>/parties" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "phone": null,
    "job_title_id": "8ff4cf0e-353b-483c-8079-b3f580959f4c",
    "stats": [{
      "groups.user": 14,
      "contracts": 10,
      "assets": 5,
      "skillsets": 4
    }],
    "updated_at": "2021-07-02T16:32:48.638Z",
    "created_at": "2021-07-02T16:32:48.638Z",
    "deleted_at": null
  }, {
    "id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "type_id": "2ddb59f4-133a-4fb0-9161-ca2417587154",
    "first_name": "Test",
    "last_name": "Contact 1",
    "job_title_id": null,
    "phone": "+14035551234",
    "email": "contact1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": null,
    "stats": [{
      "groups.user": 0,
      "contract": 0,
      "asset": 0,
      "skillset": 0
    }],
    "updated_at": "2021-06-24T04:18:12.066Z",
    "created_at": "2021-06-24T04:18:12.066Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "items": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of parties, with any given filters applied.

Note, skillsets can be added to this result as part of the skillsets include option. Skillsets however, need to be modified by the speciific parties/skillsets endpoint.

HTTP Request

GET https://<api-url>/parties

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these party IDs
group_id	null	Filter results by parties belonging to this group id
type_id	null	Filter results by the given type id
skillset_id	null	Filter results by this skillset id
keywords	null	Filter results by the given keywords. Keywords search across `name` and `description`.
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Embed/Include Parameters

Option	Description
stats	Includes stats totals. This includes contracts, assets, groups, and skillsets.

Sorting fields

Field	Description
name	Sort by name.
first_name	Sort by their first name
last_name	Sort by their last name
type	Sort by their type
phone	Sort by their phone number
email	Sort by their email
last_signin	Sort by their last signin
job_title_id	Sort by their job title
total_identities	Sort by the total number of identities
total_groups	Sort by the total number of groups they are in
total_contracts	Sort by the total contracts they are assocated with
total_skillsets	Sort by the total skillets they have
total_assets	Sort by the total assets they have
created	Sort by create date
updated	Sort by update date

LIST Party Types

These are types for the parties. See Party Type

curl "https://<api-url>/parties/~/types" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Contractor",
    "description": "Some description",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Employee",
    "description": "Some description",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of party types. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

Base Types define the behaviour of this type in the system. See Party Type object for a description of the base types.

HTTP Request

GET https://<api-url>/parties/~/types

LIST SkillSets for Party

Get a list of the skill sets and their properties for a specific party. See Party SkillSet

curl "https://<api-url>/parties/~/skillsets?party_id=e00bc820-6f56-4752-a50f-7d9b4e9ab50a" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "party_id": "e00bc820-6f56-4752-a50f-7d9b4e9ab50a",
    "skillset_id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "effective_at": "2022-01-01T12:50:00.000Z",
    "expires_at": "2023-01-01T12:50:00.000Z",
    "doc_url": "https://google.com",
    "created_at": "2023-01-01T12:35:00.000Z",
    "updated_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "party_id": "e00bc820-6f56-4752-a50f-7d9b4e9ab50a",
    "skillset_id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "effective_at": "2022-02-01T12:50:00.000Z",
    "expires_at": "2023-02-01T12:50:00.000Z",
    "doc_url": "https://google.com/2",
    "created_at": "2023-01-01T12:35:00.000Z",
    "updated_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": null
  }]
}

No pagination or sorting exists on this endpoint. It will return all the skillsets available for the given Party ID. If no skillsets are available, then an empty array is returned.

Note if the Party ID or the SkillSet ID does not exist, then an empty array will be returned.

HTTP Request

GET https://<api-url>/parties/~/skillsets

Query Parameters

Parameter	Default	Description
party_id	null	Return all the results for this party ID
skillset_id	null	Return all the results for this SkillSet ID

Note, skillset_id OR party_id MUST be given

LIST Favorites for a Party

curl "https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/favorites" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "item_id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "category": "heatmap",
    "type": "pin"
  }, {
    "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "item_id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "category": "entity",
    "type": "favorite"
  }, {
    "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "item_id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "category": "heatmap",
    "type": "favorite"
  }],
  "warnings": []
}

This endpoint retrieves the favorites for a given party/user.

NOTE, you can only change and retrieve favourites for the current logged in user

HTTP Request

GET https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/favorites

Query Parameters

Parameter	Default	Description
type	null	Filter results by this type
category	null	Filter results by this category

See 'Update' call for valid type / categories.

GET a Party

curl "https://<api-url>/parties/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "phone": null,
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "job_title_id": "8ff4cf0e-353b-483c-8079-b3f580959f4c",
    "profile": [{
      "key": "title", "val": "watchman",
      "key": "dob", "val": "2000-01-01"
    }],
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case that no party is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific party by the given id.

HTTP Request

GET https://<api-url>/parties/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the party to retrieve

Embed/Include Parameters

Option	Description
counts	Includes object count totals. This includes contracts, assets, groups, and skillsets.

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartyNotFound`	The party could not be found / invalid ID.

CREATE a new Party

curl -X POST "https://<api-url>/parties" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "phone": null,
    "job_title_id": "8ff4cf0e-353b-483c-8079-b3f580959f4c",
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "profile": [{
      "key": "job_title_id", "val": "watchman",
      "key": "welcome_template", "val": "template_key"
    }]
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "phone": null,
    "job_title_id": "8ff4cf0e-353b-483c-8079-b3f580959f4c",
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "profile": [{
      "key": "job_title_id", "val": "watchman",
      "key": "welcome_template", "val": "template_key"
    }]
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a party with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

base_type is a convenience field, and will be overwritten by whatever base type belongs in the party assigned type_id

HTTP Request

POST https://<api-url>/parties

Parameters

Attribute	Type	Restrictions	Null allowed
type_id	uuid	The type of party Entity Type	Yes
first_name	string	Max length 150	No
last_name	string	Max length 150	No
email	string	Valid email	Yes
phone	string	Valid e164 number format	Yes
avatar_media_id	uuid	Valid media ID for the avatar	Yes
avatar_url	string	Public URL for an avatar (ie, via Google)
job_title_id	uuid	Valid job title ID	Yes
addresses	Address[]	Use empty array for none	No
profile	PartyProfile[]	Use empty array for none	No

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`ePartyTypeNotFound`	Entity type ID given could not be found
400 BAD REQUEST	`eJobTitleNotFound`	Job Title ID given could not be found
400 BAD REQUEST	`eProfileKeyNotFound`	One or more of your profile keys do not exist.

UPDATE a Party

curl -X PUT "https://<api-url>/parties/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "phone": null,
    "job_title_id": null,
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "profile": [{
      "key": "job_title_id", "val": "watchman",
      "key": "welcome_template", "val": "template_key"
    }]
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "type_id": null,
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "avatar_media_id": null,
    "avatar_url": "https://avatar.url",
    "phone": null,
    "job_title_id": null,
    "addresses": [{
      "name": "Main Office",
      "country": "gb",
      "region": "nottinghamshire",
      "city": "newark",
      "locale": "collingham",
      "street": "station road",
      "unit": null,
      "postal": null,
      "lat": "52.023432",
      "long": "-0.126345"
    }],
    "profile": [{
      "key": "job_title_id", "val": "watchman",
      "key": "welcome_template", "val": "template_key"
    }]
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing party with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/parties/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the party to update

Parameters

Attribute	Type	Restrictions	Null allowed
type_id	uuid	Valid entity type ID Entity Type	Yes
first_name	string	Max length 150	No
last_name	string	Max length 150	No
email	string	Valid email	Yes
phone	string	Valid e164 number format	Yes
avatar_media_id	uuid	Valid media ID for the avatar	Yes
avatar_url	string	Avatar URL for a public image (ie via Google)
job_title_id	uuid	Valid Job Title ID	Yes
addresses	Address[]	Use empty array for none	No
profile	PartyProfile[]	Use empty array for none	No

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`ePartyNotFound`	The party could not be found / invalid ID.
400 BAD REQUEST	`ePartyTypeNotFound`	The party type could not be found / invalid ID.
400 BAD REQUEST	`eJobTitleNotFound`	Job Title ID given could not be found
400 BAD REQUEST	`eProfileKeyNotFound`	One or more of your profile keys do not exist.

UPDATE SkillSets for Parties

curl -X PUT "https://<api-url>/parties/~/skillsets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "party_id": "b54245c3-e668-46fb-80f6-acc268659bd1",
      "skillset_id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
      "effective_at": "2023-01-01T12:35:00.000Z",
      "expires_at": "2023-02-02T12:35:00.000Z",
      "doc_url": "http://test-doc.com",
      "deleted_at": "2023-03-03T12:35:00.000Z"
    }, {
      "party_id": "a4c63ede-59b7-416c-9419-6b2804f75fcc",
      "skillset_id": "de45c0e0-595f-4392-8c75-e7fade75dc09",
      "effective_at": null,
      "expires_at": null,
      "doc_url": null,
      "deleted_at": null
      }]
    }'

Note, this endpoint is idempotent. It will only edit the party/skillset combination given. A valid response will be a 200 OK, with the new state of geozones as an array

{
  "data": [{
    "party_id": "b54245c3-e668-46fb-80f6-acc268659bd1",
    "skillset_id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "effective_at": "2023-01-01T12:35:00.000Z",
    "expires_at": "2023-02-02T12:35:00.000Z",
    "doc_url": "http://test-doc.com",
    "deleted_at": "2023-03-03T12:35:00.000Z"
  }, {
    "party_id": "a4c63ede-59b7-416c-9419-6b2804f75fcc",
    "skillset_id": "de45c0e0-595f-4392-8c75-e7fade75dc09",
    "effective_at": null,
    "expires_at": null,
    "doc_url": null,
    "deleted_at": null
  }]
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint is idempontent and will update all given skillsets give for each party.

You can update multiple different parties and different skillsets in one request, up to a maximum of 50.

Note, unlike some previous endpoints, omitting skillsets will not delete them. This is because this array can have different parties and skillsets mixed.

To delete a party-skillset

Set the deleted_at to a date. null will undelete.

The deleted skillset will appear in the result payload, but will be omitted from all future lookup payloads.

HTTP Request

PUT https://<api-url>/parties/~/skillsets

Parameters

Attribute	Type	Restrictions	Null allowed
party_id	uuid	Valid Party ID	No
skillset_id	uuid	Valid SkillSet ID	No
effected_at	datetime	Valid datetime	Yes
expires_at	datetime	Valid datetime	Yes
doc_url	string	Max length 5000	Yes
deleted_at	datetime	Valid datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartiesNotFound`	Some or all of the party IDs given could not be found (Missing IDs given in the error message)
400 BAD REQUEST	`eAttemptSaveWithMissingSkillSets`	Some or more of the skillsets given could not be found. (Missing IDs given in error message.)

UPDATE Favorites for a Party

curl -X PATCH "https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/favorites" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
        "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
        "item_id": "aa22e6df-867f-4504-a700-18db11b8abd3",
        "category": "heatmap",
        "type": "pin",
        "deleted_at": "2023-03-03T12:35:00.000Z"
      }, {
        "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
        "item_id": "26e58965-3023-4bd0-b1ca-d82654cb14fe",
        "category": "heatmap",
        "type": "favorite",
        "deleted_at": null
      }]
    }'

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "item_id": "aa22e6df-867f-4504-a700-18db11b8abd3",
    "category": "heatmap",
    "type": "pin",
    "deleted_at": "2023-03-03T12:35:00.000Z"
  }, {
    "party_id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "item_id": "26e58965-3023-4bd0-b1ca-d82654cb14fe",
    "category": "heatmap",
    "type": "favorite",
    "deleted_at": null
  }]
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint is idempontent and will update all given favourites for the given party, up to a maximum of 50 per request

Note, unlike some previous endpoints, omitting favorites will not delete them.

Missing item_ids

The external associations are loosely coupled; therefore, no validation lookups will occur to validate the given item_ids are correct.

Using party_id

For REST consistency, every element must have a party_id. It should only be the same user as that in the URL - however, it must also be that of the current user.

To delete a party-favourite

Set the deleted_at to a date. null will perform no action.

The deleted favorite will appear in the result payload, but will be omitted from all future lookup payloads.

HTTP Request

PATCH https://<api-url>/parties/:id/favorites

Parameters

Attribute	Type	Restrictions	Null allowed
item_id	uuid	Valid item ID for the foreign object	No
type	enum	Valid supported type	No
category	enum	Valid supported category	No
deleted_at	datetime	Valid datetime	Yes

Supported categories

heatmap
entity

Supported types

pin
favorite

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartyNotFound`	Party with the given ID could not be found
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details

BATCH UPDATE Parties

curl -X PATCH "https://<api-url>/parties" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9"
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8"
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa"
      "deleted_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9"
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "deleted_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch Party fields. To help maintain the integrity of Party, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/parties

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
suspended_at	datetime	Will de-activate (suspend) the party if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the party if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' parties endpoint.

DELETE a Party

curl -X DELETE "https://<api-url>/parties/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given party by id.

HTTP Request

DELETE https://<api-url>/parties/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartyNotFound`	The party could not be found / invalid ID.

LIST Users

curl "https://<api-url>/parties/~/users" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "username": "test-username",
    "system_admin": true,
    "allow_sso": true,
    "allow_otp": false,
    "last_signin": "2021-06-24T04:18:12.066Z",
    "suspended_at": null
  }, {
    "id": "8b9fbb06-c350-49b8-8622-6b35338b9353",
    "first_name": "Test",
    "last_name": "Contact 1",
    "email": "contact1@sixfactorsolutions.com",
    "username": "Bob",
    "system_admin": false,
    "allow_sso": true,
    "allow_otp": false,
    "last_signin": "2023-06-24T04:18:12.066Z",
    "suspended_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20,
    "items": 2
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of users, with any given filters applied.

Please note: - party_id Is the same as the party this party belongs to - first_name, last_name, email belong to the party, and are just given here for convenience.`

HTTP Request

GET https://<api-url>/parties/~/users

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these party IDs
keywords	null	Filter results by the given keywords. Keywords search across `name` and `description`.
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Sorting fields

Field	Description
name	Sort by name.
first_name	Sort by their first name
last_name	Sort by their last name
email	Sort by their email
last_signin	Sort by their last signin
created	Sort by create date
updated	Sort by update date

GET a Party's User

curl "https://<api-url>/parties/:id/users" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "id": "f983e02d-732b-4b7a-a990-c911ed4a56ad",
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "username": "test-username",
    "system_admin": true,
    "allow_sso": true,
    "allow_otp": false,
    "identities": [{
      "type": "email",
      "value": "sso_email@example.com"
    }],
    "last_signin": "2021-06-24T04:18:12.066Z",
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "suspended_at": null
  }
}

In the case that no party is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific party by the given id.

Please note: - id this is the party ID for which the user will relate to

HTTP Request

GET https://<api-url>/parties/<id>/users

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the party to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartyNotFound`	The party could not be found / invalid ID.

UPDATE a Party User

curl -X PUT "https://<api-url>/parties/3823424f-dcc3-40b1-82e5-d71b0a194c69/users" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "username": "test-username",
    "system_admin": true,
    "allow_sso": true,
    "allow_otp": false,
    "last_signin": "2021-06-24T04:18:12.066Z",
    "identities": [{
      "type": "email",
      "value": "sso_email@example.com"
    }],
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "suspended_at": null
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "first_name": "Test",
    "last_name": "User1",
    "email": "test1@sixfactorsolutions.com",
    "username": "test-username",
    "system_admin": true,
    "allow_sso": true,
    "allow_otp": false,
    "last_signin": "2021-06-24T04:18:12.066Z",
    "identities": [{
      "type": "email",
      "value": "sso_email@example.com"
    }],
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "suspended_at": null
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

Will update the user for the given party ID. If the party does not have a user, then one is created.

ID can be given in the payload but is ignored.
first_name, last_name, email are from the party. They will be ignored, and can be omitted.
last_signin this is a read only field. It can be omitted. If given, will be ignored.
allow_otp these are One-Time-Passwords aka Guest Logins.

HTTP Request

PUT https://<api-url>/parties/<id>/users

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the party to update

Parameters

Attribute	Type	Restrictions	Null allowed
username	string	Max length 45	Yes
system_admin	boolean	Only a system admin can elevate or remove a system admin from a user	No
allow_sso	boolean	boolean	No
allow_otp	boolean	boolean	No
identities	PartyIdentity[]	Use empty array for none	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`ePartyNotFound`	The party could not be found / invalid ID.
400 BAD REQUEST	`eIdentityNotValid`	One or more of your identities are not valid.
400 BAD REQUEST	`eIdentityNotUnique`	One or more of your identities is currently in use by another user.

GET Settings for a Party User

curl "https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/users/settings" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": {
    "id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "settings": [{
      "key": "welcome_template_id",
      "val": "deadc0de-732b-4b7a-a990-c911ed4a56ad",
    }],
    "application_state": {
      "some_state": 123
    }
  },
  "warnings": []
}

This endpoint retrieves the settings for a given party/user.

Please note the following: - application_state is the legacy storage medium, and will be phased out in place of settings

NOTE, you can only change and retrieve settings for the current logged in user

HTTP Request

GET https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/users/settings

UPDATE Favorites for a Party

curl -X PATCH "https://<api-url>/parties/8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7/users/settings" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": {
      "id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
      "settings": [{
        "key": "welcome_template_id",
        "val": "deadc0de-732b-4b7a-a990-c911ed4a56ad",
      }],
      "application_state": {
        "some_state": 123
      }
    }'

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": {
    "id": "8d2c4dff-8055-4d5d-ab53-bfe10ba6bde7",
    "settings": [{
      "key": "welcome_template_id",
      "val": "deadc0de-732b-4b7a-a990-c911ed4a56ad",
    }],
    "application_state": {
      "some_state": 123
    }
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

Will update the settings for the user.

NOTE, you can only change and retrieve settings for the current logged in user

HTTP Request

PATCH https://<api-url>/parties/:id/users/settings

Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Valid party ID	No
application_state	any	Legacy state
settings	PartySettings[]	Use empty array for none	No
suspended_at	timestamp	Valid timestamp	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`ePartyNotFound`	Party with the given ID could not be found
400 BAD REQUEST	`eSettingKeyNotFound`	One or more of your profile keys do not exist.
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details

BATCH UPDATE Users

curl -X PATCH "https://<api-url>/parties/~/users" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99"
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "suspended_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99"
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "suspended_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch user fields. To help maintain the integrity of a party's user, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/parties/~/users

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
suspended_at	datetime	Will de-activate (suspend) the party if set to a date. `null` means re-activate	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' parties endpoint.

Search

Endpoints for searching for resources across the system.

Important information for changes

The existing endpoints give all the information required in one endpoint. While this is incredibly efficient for the frontend especially while the dataset is small, this is not scalable.

As the system expands, we will be increasing the number of potential results in one request. Furthermore, there will be the possibility of many different objects, where a one-schema-fits-all approach will no longer be effective.

Remember, one of the biggest causes of slow APIs is not the data lookup or processing, but the transferrance of large payloads from the backend to the frontend. In many times, it's not just the data, but the schema itself that carries a heavy tax.

So, to make this scalable, we need to

Make the return schema minimally descriptive
Make the schema relevant to all returned resources
Make the schema minimal to handle large payloads.

With the information returned, it is likely you're going to need more. To this end, you can use the type along with the collated ids, to perform one further lookup per resource type, to and endpoint to retrieve that information, for instance:

/entities?ids[]={id}&ids[]={id}

While this means a search function may now need 2 or 3 requests as opposed to 1, it also saves returning huge amounts of data when only 1 skinny request is required. It opens the door to many other scalable strategies such as lazy loading, deferred loading, etc.

Future Considerations

While the current format deals with result sets numbered potentially in the hundreds, moving into the thousands is going to start being problematic.

When this occurs, we will start to implement a cursoring style result, where each result set will be limited to x number, with a cursor given for the next result set.

LOCATIONS Search

curl "https://<api-url>/search/locations?bound[]=POLYGON((50 -100, 51, -101))&keywords=Calgary&types[]=asset&types[]=entity" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "dd4e2c04-7c40-43a8-9eb9-bb9af322f800",
    "type": "asset",
    "name": "Example Result 1",
    "wkt": null,
    "lat": "51.232",
    "long": "105.123"
  }, {
    "id": "e9c72528-e52b-4cc8-960d-2d9726a4b0bb",
    "type": "asset",
    "name": "Another Example Result",
    "wkt": null,
    "lat": "52.121",
    "long": "104.111"
  }, {
    "id": "6f643b1e-40cb-45a8-abf9-0701ff227829",
    "type": "entity",
    "name": "A result C",
    "wkt": null,
    "lat": "51.555",
    "long": "105.105",
    "assets": [{
      "id": "dd4e2c04-7c40-43a8-9eb9-bb9af322f800",
      "type": "asset",
      "name": "An asset belonging to an entity",
      "wkt": null,
      "lat": "51.232",
      "long": "105.123"
    }]
  }, {
    "id": "7ebfd79f-83d0-464c-b87c-39cc99a438ab",
    "type": "entity",
    "name": "Further result",
    "wkt": null,
    "lat": "48.121",
    "long": "99.111",
    "assets": []
  }],
  "warnings": []
}

This endpoint retrieves a result set of locations, with any given filters applied.

HTTP Request

GET https://<api-url>/search/locations?bound[]={bounding-boxes}&types[]={types}&keywords={keywords}

Query Parameters

Parameter	Default	Description
types[]	[`asset`, `entity`]	Only include these types. See Search Result Types. If `asset` AND `entity` is given, then each entity will have a sub attribute named `assets`, which will contain all the assets under this entity.
keywords	null	Filter results by the given keywords. See below for possible filter choices.
bound[]	null	Wkt, REQUIRED: Restrict results to this bounding box.

The Keywords Filter

All words given are performed in an AND fashion
You can use keywords: AND, OR, and NOT
You can use brackets to make the order of presidence explict
Will search across NAME, ADDRESS, details of the given types[]

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eInvalidKeywordQuery`	There was an error in your keyword query. Ie, check brackets are terminated etc.

Services

NOTE Section still under development

Methods for dealing with the Service object in the system.

Note on development

Currently, this endpoint is providing a 'facade' for the legacy service endpoint in the system. The id for the services are the same as the service_id for the existing services. Legacy endpoints at this juncture can still be used interchangably, but newer functionality should be preferred where possible as older legacy endpoints will be deprecated as the data model is migrated.

LIST services

curl "https://<api-url>/services" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Catering",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Floor Cleaning",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "email": "floorcleaning@example.com",
    "phone": "+17789889888",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": "2023-01-02T12:23:44.000Z",
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of services, with any given filters applied.

HTTP Request

GET https://<api-url>/services

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these service IDs
keywords	null	Filter results by the given keywords. Keywords search across `name`.
type_id	null	Filter results by this type id
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
category	Sort by category
type	Sort by type
created	Sort by create date
updated	Sort by update date

LIST Service Types

These are types for the services. See Service Type

curl "https://<api-url>/services/~/types" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Service Type A",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Service Type B",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of service types. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

HTTP Request

GET https://<api-url>/services/~/types

LIST Service Categories

These are categories for the services. See Service Category

curl "https://<api-url>/services/~/categories" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "300d1740-7b7c-4aaf-a965-e4a096bd3f99",
    "name": "Service Category A",
    "created_at": "2023-04-28T20:46:27.270Z"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Service Category B",
    "created_at": "2023-04-28T20:46:27.270Z"
  }]
}

This endpoint retrieves a result set of service categories. Note, this is a catalogue endpoint which will return the entirity of the dataset. No sorting or pagination is done since it is expected this will be done on the receiver side.

HTTP Request

GET https://<api-url>/services/~/categories

GET a service

curl "https://<api-url>/services/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A valid response will contain the single result in the data attribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Catering",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case that no service is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific service by the given id.

HTTP Request

GET https://<api-url>/services/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the service to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eServiceNotFound`	The contract could not be found / invalid ID.

CREATE a new Service

curl -X POST "https://<api-url>/services" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "A created service",
    "description": "Created service description",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "A created Entity",
    "description": "Created service description",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a service with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/services

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
email	string	Valid email	Yes
phone	string	Valid e164 phone	Yes
type_id	uuid	Valid entity type ID Service Type	Yes
category_id	uuid	Valid industry ID Service Category	Yes
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eServiceTypeNotFound`	Service type ID given could not be found
400 BAD REQUEST	`eServiceCategoryNotFound`	Service category ID given could not be found

UPDATE a Service

curl -X PUT "https://<api-url>/services/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "An updated service",
    "description": "Updated service description",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "An updated service",
    "description": "Updated service description",
    "email": "serviceemail@example.com",
    "phone": "+17789891122",
    "category_id": "7fa79cdd-7ffe-4628-a057-d8212eee421a",
    "type_id": "0fc66bc3-b6af-47c3-8a0f-76dbf2eb7f8c",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing service with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/services/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the service to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
email	string	Valid email	Yes
phone	string	Valid e164 phone	Yes
type_id	uuid	Valid entity type ID Service Type	Yes
category_id	uuid	Valid industry ID Service Category	Yes
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eServiceNotFound`	Service ID given could not be found
400 BAD REQUEST	`eServiceTypeNotFound`	Service type ID given could not be found
400 BAD REQUEST	`eServiceCategoryNotFound`	Service category ID given could not be found

BATCH UPDATE Entities

curl -X PATCH "https://<api-url>/services" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "data": [{
      "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
      "suspended_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
      "deleted_at": "2023-01-01T12:35:00.000Z",
    }, {
      "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
      "suspended_at": "2023-01-01T12:35:00.000Z",
      "deleted_at": "2023-01-01T12:35:00.000Z"
    }, {
      "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
      "suspended_at": null,
      "deleted_at": null
    }]
  }'

A valid response will be a 200 OK. Any errors encountered when batch updating the objects will be returned in the errors array.

{
  "data": [{
    "id": "6fd5b5c4-0978-49f6-b301-85f60434c1b9",
    "suspended_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "e3d53daf-87d4-4427-a215-000cce6d0f99",
    "deleted_at": "2023-01-01T12:35:00.000Z",
  }, {
    "id": "aa122ac3-54b0-4b90-93cd-d32e907980c8",
    "suspended_at": "2023-01-01T12:35:00.000Z",
    "deleted_at": "2023-01-01T12:35:00.000Z"
  }, {
    "id": "48dd8d74-0aee-4fae-8417-d0466c74fbaa",
    "suspended_at": null,
    "deleted_at": null
  }]
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint facilitates the updating of batch service fields. To help maintain the integrity of a service, only selected fields can be updated in this manner.

For this, send an array in data with an id for each group object you wish to update, and the attributes you wish to update on that object.

The response to this endpoint is an array of errors with any errors that occurred during this operation. An empty array means the operation was successful and there were no failures.

HTTP Request

PATCH https://<api-url>/services

Accepted PATCH Parameters

Attribute	Type	Restrictions	Null allowed
id	uuid	Required	No
suspended_at	datetime	Will de-activate (suspend) the service if set to a date. `null` means re-activate	Yes
deleted_at	datetime	Will delete the service if set to a date. `null` means undeleted.	Yes

Note, for delete, the date will be overriden with the current date that the operation took place.

Error Responses

These will appear in the errors array using the Batch Update Error format. For possible errors, see the list given for the 'update' services endpoint.

DELETE a Service

curl -X DELETE "https://<api-url>/services/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given service by id.

HTTP Request

DELETE https://<api-url>/services/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eServiceNotFound`	The service could not be found / invalid ID.

SkillSets

NOTE Section still under development

Methods for dealing with the SkillSet object in the system.

LIST SkillSet

curl "https://<api-url>/skillsets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Snow Safety",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": "2023-01-02T12:23:44.000Z",
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves a result set of skillsets, with any given filters applied.

HTTP Request

GET https://<api-url>/skillsets

Query Parameters

Parameter	Default	Description
ids[]	null	Filter results by these skillset IDs
keywords	null	Filter results by the given keywords. Keywords search across `name`.
sort	+name	Sorts by the given field & direction (-/+).
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

Sorting fields

Field	Description
name	Sort by name.
description	Sort by description
total_parties	Sort by total parties with this skillset
total_expired	Sort by total parties where this skillset has expired
created	Sort by create date
updated	Sort by update date

GET a SkillSet

curl "https://<api-url>/skillsets/:id" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A valid response will contain the single result in the data attribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": null,
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }
}

In the case that no skillset is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves a specific skillset by the given id.

HTTP Request

GET https://<api-url>/skillsets/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the skillset to retrieve

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eSkillSetNotFound`	The contract could not be found / invalid ID.

CREATE a new SkillSet

curl -X POST "https://<api-url>/skillsets" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 201 CREATED, with the created object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an validation error, a 400 BAD REQUEST will be returned.

This endpoint will create a skillset with the given properties. Note, id is not accepted, and will be automatically generated and assigned.

HTTP Request

POST https://<api-url>/skillsets

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eSkillSetTypeNotFound`	SkillSet type ID given could not be found
400 BAD REQUEST	`eSkillSetCategoryNotFound`	SkillSet category ID given could not be found

UPDATE a SkillSet

curl -X PUT "https://<api-url>/skillsets/3823424f-dcc3-40b1-82e5-d71b0a194c69" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json" \
  --data '{
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }'

A valid response will be a 200 OK, with the updated object in the data atttribute

{
  "data": {
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Fire Extinguisher",
    "description": "Lorem ipsum dolor sit amet, consectetur adipiscing...",
    "suspended_at": "2023-01-01T12:45:00.000Z"
  }
}

In the case of an valdiation error, a 400 BAD REQUEST will be returned.

This endpoint will update an existing skillset with the new payload. The endpoint expects the entire object to be given in the parameters to better fulfill the goal of REST idempotency.

ID is not accepted as a body parameter, and should only be given in the URL.

HTTP Request

PUT https://<api-url>/skillsets/<id>

URL Parameters

Parameter	Data Type	Description
ID	uuid	The ID of the skillset to update

Parameters

Attribute	Type	Restrictions	Null allowed
name	string	Max length 150	No
description	string	Max length 5000	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eValidationError`	Parameters given were invalid. Check error message for details
400 BAD REQUEST	`eSkillSetNotFound`	SkillSet ID given could not be found

DELETE a SkillSet

curl -X DELETE "https://<api-url>/skillsets/deadc0de-4333-49d8-bec8-6454ca3f6ce9" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

A successful delete with return a 204 NO CONTENT

The endpoint will delete the given skillset by id.

HTTP Request

DELETE https://<api-url>/skillsets/<id>

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eSkillSetNotFound`	The skillset could not be found / invalid ID.

Templates

NOTE Section still under development - new fields and endpoints will be added as time goes on

Currently only returning ID/name/type

LIST Templates

curl "https://<api-url>/templates" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Welcome Template 2023",
    "type_id": "0e1d0780-bff5-4df5-b3dc-7bd0e25cd524",
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Terms of Use acceptance 2020",
    "type_id": "0e1d0780-bff5-4df5-b3dc-7bd0e25cd524",
    "created_at": "2022-01-01T12:35:00.000Z",
    "updated_at": "2022-01-01T12:35:00.000Z",
    "deleted_at": null
  }],
  "pagination": {
    "page": 0,
    "per_page": 20
  },
  "sort": [{
    "field": "name",
    "dir": "asc"
  }],
  "warnings": []
}

This endpoint retrieves all templates.

HTTP Request

GET https://<api-url>/templates

Query Parameters

Parameter	Default	Description
keywords	null	Filters results by the given keywords
sort_by	+name	Sorts by the given field & direction (-/+). Fields permitted are `name`, `locations`, `status`
page	0	Pagination: which page to view
per_page	20	Pagination: how many results per page to show

LIST Template Types

curl "https://<api-url>/templates/~/types" \
  -H "X-Client-Key: client-key" \
  -H "Authorization: your-auth-token" \
  -H "Content-Type: application/json"

All results will be returned in a 'data' array. An empty array means no results were found.

{
  "data": [{
    "id": "abfe045b-814e-4d31-98f5-f3d0a23437f1",
    "name": "Welcome Template"
  }, {
    "id": "a88fe8d7-f04a-4089-aed9-8df56b2c7a12",
    "name": "Terms of Use Acceptance"
  }]
}

This endpoint retrieves all template types. This is considered a catalog endpoint, and is not paginated. There are no filters or modifiers available.

HTTP Request

GET https://<api-url>/templates/~/types

Users

These are endpoints for dealing with user access in the system ONLY. For detail on the actual party/user profile, see the Parties endpoint

curl "https://<api-url>/users/me" </span>
  -H "X-Client-Key: client-key" </span>
  -H "Authorization: your-auth-token" </span>
  -H "Content-Type: application/json"

The baseline response will look like the following

{
  "data": {
    "party_id": "a0b460d0-2bfb-44c8-9c50-e86dbbcc0b0a",
    "permissions": [{
      "op_group_id": null,
      "permissions": [
        "dashboard.view"
      ]
    }, {
      "op_group_id": "c27c4e6f-4560-49a2-b1fa-5c344d1c4698",
      "permissions": [
        "assets.import",
        "assets.create",
        "assets.read"
      ]
    }],
    "settings": []
  },
  "warnings": []
}

In the case that no party is found, a 400 BAD REQUEST will be returned.

This endpoint retrieves login configuration, settings, and permissions for the current logged in user.

The current returned properties:

party_id The current party ID of the logged in user (not the user ID)
permissions A list of permissions grouped by the operational group that issues them. If the group is null then the permissions are directly applied to a user group and not derived from an operational group.
settings A list of all the custom settings for this user in the context on the current tentant.

HTTP Request

GET https://<api-url>/users/me

Error Responses

HTTP Status	Error Code	Description
400 BAD REQUEST	`eUserNotFound`	If the user could not be found. Since it pulls the user id from the current session, this would mean the user record could not be matched or is missing. This may be as a result of the user being deleted since the token was issued.

Type: Asset

This is an asset in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Asset ID
name	string	No	The asset name
description	string	Yes	Description for the asset
type_id	uuid	Yes*	The type for the asset. See Asset Type
entity_id	uuid	Yes	Valid entity ID. Must be `null` on container types
parent_id	uuid	Yes	Valid parent ID, depending on restrictions given by type
phone*	string	Yes	Valid e164 number format
floor_unit*	string	Yes	Max length 150, unit number
year_built*	string	Yes	Max length 50, if building, year built. Will move to custom field.
building_floor*	string	Yes	Max length 50. Will move to custom field.
num_floors_units*	string	Yes	Max length 50. For buildings, number of floors or units. Will move to custom field.
strata*	string	Yes	Max length 50. Strata ID for building. Will move to custom fields
service_ids*	uuid[]	No	Valid service ids. Use empty array for empty.
party_ids*	uuid[]	No	Valid party ids. Use empty array for empty.
contract_ids*	uuid[]	No	Valid contract ids. Use empty array for empty.
address*	Address	Yes	If type permits address, otherwise `null`
geo*	GeoZone	Yes	If type permits geo, otherwise `null`
is_hidden	boolean	True if this asset is hidden on the map	No
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

* These entries only show on non-shallow payloads ** Please be aware that not all these fields apply to containers/locations alike. Some will be ignored as we migrate the database

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the contract was last updated
created_at	datetime	No	When the contract was created

Type: Asset Type

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Asset Type ID
name	string	No	The default type name
config	object	No	Configurations for the type

Type configuration object

Name	Type	Allow Null	Description
require_parent	boolean	No	If `true` then any asset with this type requires a parent.
allow_parents	uuid[]	No	Only allow parents with these uuids. If none given, then does not permit parents.
can_inherit	boolean	No	If `true`, an asset with this type will inherit addresses/geo information from it's parents.
permit_address	boolean	No	If `true`, an asset with this type may have a civic address.
permit_geo	boolean	No	If `true`, an asset with this type may have a geo location.
geo_update_freq	integer	Yes	If not null, this is the frequency in which the asset can receive updates from the wild.
is_container	boolean	No	If `true`, this is a container only, and does not contain any sub-objects other than assets.
is_system	boolean	No	If `true`, this is a system type, and therefore has heavy restrictions around it's updating.

Note, a type could end up in an inconsistent state if require_parent is true and allow_parents is empty. Updating a type to this state will throw an error.

The following are immutable fields provided

Name	Type	Allow Null	Description
created_at	datetime	No	When this type was created
updated_at	datetime	Yes	When this type was last updated
deleted_at	datetime	Yes	If this type is deleted. (Will be generally be omitted.)

Type: Contract

This is an contract in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Contract ID
name	string	No	The contract name
description	string	Yes	The contract description, if any
starts_at	datetime	Yes	ISO8601 compliant timestamp, if any
expires_at	datetime	Yes	ISO8601 compliant timestamp, if any
url	string	Yes	Must be a valid url. Max 1000 chars.
entity_ids*	uuid[]	No	Entities assigned to this contract
media_ids*	uuid[]	No	Medias assigned to this contract
owners*	PartyAssociation[]	No	Owners assigned to this contract
contacts*	PartyAssociation[]	No	Contacts assigned to this contract
suspended_at	datetime	Yes	When set to not-null, will override with current datetime

* Not on shallow payloads (ie, only on get one, response from create/updates)

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the contract was last updated
created_at	datetime	No	When the contract was created

Type: Contract Role

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Role ID
name	string	No	The default role name
type	enum	No	Either `contact` or `owner`
description	string	Yes	A description of this role
created_at	datetime	No	When this role was created.

Type: DataZone

This is a datazone in the system, being either at:

Geo DataZone
Commercial DataZone

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Datazone ID
name	string	No	The datazone name
type	enum	No	DataZone Type
is_dynamic	boolean	No	Default `true`.
owner_ids	uuid[]	No	Valid party IDs (Can use legacy user ids)
addresses	Address[]	No	Addresses, only valid on type `geo`. Use empty array `[]` otherwise. Not included on simplified datazone lists
description	string	Yes	The datazone description
inherit_ids	uuid[]	No	Datazone IDs of groups it inherits from Not included on simplified datazone lists
industry_ids	array of uuids	No	Commercial only Valid Industry IDs Not included on simplified datazone lists
entity_ids	array of uuids	No	Valid Entity IDs Not included on simplified datazone lists
contract_ids	array of uuids	No	Valid Contract IDs Not included on simplified datazone lists
suspended_at	datetime	Yes	When set to not-null, will override with current datetime

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
stats	{ type / count }[]	No	A list of all object types and counts within the datazone
inherits	DataZone[]	No	When expanded, all of the inherited objects.
updated_at	datetime	Yes	When the datazone was last updated
created_at	datetime	No	When the datazone was created

Type: DataZone Type

This is an enumeration of possible datazone types.

Type	Description
geo	A geo type datazone
commercial	A commercial datazone

Type: Entity

This is an entity in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Entity ID
name	string	No	The entity name. Max 150 chars
description	string	Yes	The entity description. Max 5000 chars.
type_id	uuid	No	The type ID for this entity. (Current types are retrieved via endpoint)
industry_id	uuid	Yes	The industry this entity is assigned to. (Industries can be pulled via endpoint)
phone	string	Yes	Must be valid e164 format
url	string	Yes	Must be a valid url. Max 1000 chars.
addresses*	Address[]	No	Addresses for the entity
contract_ids*	uuid[]	No	Contracts assigned to this entity
service_ids*	uuid[]	No	Services assigned to this entity
owners*	PartyAssociation[]	No	Owners assigned to this entity
contacts*	PartyAssociation[]	No	Contacts assigned to this entity
suspended_at	datetime	Yes	When set to not-null, will override with current datetime
permissions	string[]	No	When returned, it is a list of all the permissions the current user can perform on this object.

* Not on shallow payloads (ie, only given on get one, responses from create/updates)

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
stats	{ type / count }[]	No	(Supplmentary not part of the main resource object): A list of all object types and counts within the group
updated_at	datetime	Yes	When the entity was last updated
created_at	datetime	No	When the entity was created

Type: Entity Type

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Type ID
name	string	No	The default type name
description	string	Yes	A description of this type
base_type	enum	No	One of the base types given below

Base Types

Name	Description
client	Client base type
vendor	Vendor base type

Type: Entity Role

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Role ID
name	string	No	The default role name
type	enum	No	Either `contact` or `owner`
description	string	Yes	A description of this role
created_at	datetime	No	When this role was created.

Type: Feature

This is an feature in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Feature ID
name	string	No	The given feature name
permission	string	No	The assigned system permission for this feature set
is_system	boolean	No	If a system feature, then it cannot be edited/removed.

Type: Feature Category

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Category ID
name	string	No	The default category name
sys_name	string	Yes	The system name for this category, if a system field.
parent_id	uuid	Yes	If given, the parent of the category (ie, this is a sub category)

Please note, only categories and sub-categories are supported. Categories beyond 1-level deep are not supported at this time

Type: Group

This is a group in the system, containing a collection of objects ("items") given by the Group Type

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Group ID
name	string	No	The group name
type	enum	No	Group Type
owner_ids	uuid[]	No	Valid party IDs (can also use legacy user ids) Not included on simplified group lists
description	string	Yes	The group description
items	uuid[]	No	Contents of the group, depending on `type` Not included on simplified group lists
inherit_ids	uuid[]	No	Group IDs of groups it inherits from Not included on simplified group lists
meta	object	Yes	Specific configuration for the `type`
is_system	boolean	No	Immutable. If group is a system group.
suspended_at	datetime	Yes	If the group has been suspended. `null` means active.

Expanded / Readonly

As with most resources, there are certain fields that are read only. They are accepted in create/updated, but ignored.

Name	Type	Can be Null	Description
stats	{ type / count }[]	No	(Supplmentary not part of the main resource object): A list of all object types and counts within the group
updated_at	datetime	Yes	When the group was last updated
created_at	datetime	No	When the group was created

META object

META: For groups of type user

{
  "email": "someaddress@email.com"
}

META: For groups of type territory.

{
  "addresses": [{
    "country": "United States"
  }, {
    "country": "Canada",
    "region": "Alberta",
    "locale": "Rocky View County"
  }, {
    "country": "Canada",
    "region": "Alberta",
    "city": "Calgary",
    "street": "1st St NW"
  }, {
    "country": "Canada",
    "postal": "T3A 0Z0"
  }]
}

Depending on the group type, different data options are permitted. The following are supported for the different group types:

Group Type	Data Key	Description
`user`	`email`	Email relating to this group
`territory`	`addresses[]`	An array of Address[] objects

Type: Group Type

This is an enumeration of possible group types.

Type	Description
user	A group of `parties` of type `user`
territory	A group of `territories`
feature	A group of `features`
operation	An operational group

Type: Heatmap

This is a Heatmap configuration in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Heatmap Configuration ID
name	string	No	The name of the heatman
description	string	Yes	Description for the heatmap
type	enum	No	Type of Heatmap, one of `system`, `business`, or `user`
owner_ids*	uuid[]	No	Valid party ids. Use empty array for empty.
group_ids*	uuid[]	No	Valid group ids. Use empty array for empty.
metrics	Heatmap Metric[]	No	Valid array of metrics to caculate
suspended_at	datetime	When set to not-null, will override with current datetime	Yes

* These entries only show on non-shallow payloads

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the contract was last updated
created_at	datetime	No	When the contract was created

Type: Heatmap Metric

This is a metric used to calculate data in the heatmap.

Name	Type	Description
field_id	uuid	null
label	string	A reference/name/label to use for this metric.
ref	string	Reference for this metric. Used to link back to different visualization metrics.
calc	enum	One of the possible calculation metrics, accepted: `sum`, `count`, `avg`, `min`, or `max`.
ranges	integer[]	Between 0 and 100. Ranges for use in visualization.

Type: Heatmap Query

This is the result set from a Heatmap executed query.

Top Level

Name	Type	Description
zoom	integer	Zoom level of this result 0-16
bound	string	WKT of the bounding box used for this operation
clusters	array[]	Array of clusters returned from this query

Clusters

Name	Type	Description	Allow Null
datazone_id	uuid	If given, this cluster data belongs to a datazone. If null, then it does not.	Yes
pins	array[]	Array of data pins for this cluster

Pins

Name	Type	Description	Allow Null
lat	string	Valid latitude, range `-90` to `90`, If `field` is given, then this is `null`	Yes
long	string	Valid longitude, range `-180` to `180`, if `field` is given, then this is `nu;;`	Yes
field	string	The field value used for that group. If a group is given, then long and lat are `null`	Yes
count	integer	Total number of items in a cluster pin. Could be `0`	No
metrics	array[]	Total number of metrics in this cluster	No

Metrics

Note, these are different than the Heatmap Metric type

Name	Type	Description	Allow Null
field_id	uuid	The field ID used to generate this result metric	No
ref	string	Reference field for this result	No
percent	number	Percent value in comparison to the whole dataset.	No
total	number	Raw total according to the metric's heatmap calculation

Type: Industry

This is an industry in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Industry ID
name	string	No	The industry name
archived_at	datetime	Yes	When set to not-null, item is archied.

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
created_at	datetime	No	When the industry was created

Type: Job Title

This is a job title in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Job Title ID
name	string	No	The Job Title name
archived_at	datetime	Yes	When set to not-null, item is archied.

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
created_at	datetime	No	When the industry was created

Type: Party

This is a party in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Party ID
type_id	uuid	Yes	The type of party Entity Type
first_name	string	No	Max length 150
last_name	string	No	Max length 150
email	string	Yes	The administrative email for the party
phone	string	Yes	The administrative phone for the party Valid e164 number format
avatar_media_id	uuid	Yes	The avatar for the party (media ID)
avatar_url	string	Yes	URL for the avatar if using a public URL (ie, via Google)
job_title	uuid	Yes	The job title for the party (job title ID)
addresses*	Address[]	No	Addresses for the entity. Use empty array for none.
profile*	PartyProfile[]	No	Profile entries (to be migrated to custom fields) Use empty array for none

* Not on shallow payloads (ie, only given on get one, responses from create/updates)

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the party was last updated
created_at	datetime	No	When the party was created

Type: Party Association

This is an association between a party and a host object.

As an example, this defines the 'role' that a party has when associated with an entity. (ie, Primary Contact, Account Exec)

The roles are retrieved from the individual resource endpoints that they are for.

Name	Type	Allow Null	Description
id	uuid	No	Party ID
role_id	uuid	No	The role from the appropriate mapping table

Type: Party Type

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Type ID
name	string	No	The default type name
description	string	Yes	A description of this type
base_type	enum	No	One of the base types given below

Base Types

Type	Description
user	Party is of the type user
contact	Party is of the base type contact

Type: Party Identity

These are identities assigned to the party. An identity is a way a user can log into the system.

Currently only the "email" identity type is supported.

The combination of type and identity must be unique across the system for that client. If it is not, then an 400 BAD REQUEST is returned.

Identity

Field	Description
`type`	The type of identity. See valid types.
`identity`	The identifing key for this identity type.

Supported Types

Type	Description
`email`	Use this email as the user's identity

Type: Party Profile

Profile items are currently given in the key/val format as per Key/Val Object.

The following keys are accepted:

Key	Description
`title`	Text, max length 150
`dob`	Text, max length 150
`is_operational`	Text, max length 150

Type: Party Settings

Settings items are currently given in the key/val format as per Key/Val Object.

The following keys are accepted:

Key	Description
`welcome_template_id`	UUID (ID from `/templates?type=welcome`)

Type: Party SkillSet

These are instances of skillsets assigned to the party.

Name	Type	Allow Null	Description
party_id	uuid	No	The party ID
skillset_id	uuid	No	The skillset ID
effective_at	datetime	Yes	The date time this skillset is effective from
expires_at	datetime	Yes	The date time this sillset expires for this party
doc_url	string	Yes	A document link. Max length 5000

Type: Search Result

This is a search result in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	The ID for the found object
type	Search Result Type	No	The type for this ID
name	string	The name for this ID/type resource
wkt	string	If given, the WKT of this object.
lat	string	If given, the latitude of this object.
long	string	If given, the longitude of this object.

Type: Search Result Type

The different kind of types that can be searched/retrieved.

Type	Is Default	Description
`asset`	Yes	An asset (address or geo location)
`entity`	Yes	An entity (via it's address)
`party`	No	Via it's assigned assets, NOT it's own address
`service`	No	Via it's assigned assets

Type: Service

This is a service in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Service ID
name	string	No	The service name
email	string	Yes	Valid email
phone	string	Yes	Valid e164 phone
description	string	Yes	The service description, if any
type_id	uuid	No	The Service Type uuid
category_id	uuid	No	The Service Category uuid
suspended_at	datetime	Yes	When set to not-null, will override with current datetime

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the service was last updated
created_at	datetime	No	When the service was created

Type: Service Type

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Service type ID
name	string	No	The service type name
created_at	datetime	No	When this service type was created

Type: Service Category

The following are the attributes given in the REST object.

Name	Type	Allow Null	Description
id	uuid	No	Service Category ID
name	string	No	The service category name
created_at	datetime	No	When this service category was created

Type: Skill Set

This is a skillset in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Skill Set ID
name	string	Max length 150	No
description	string	Max length 5000	No
suspended_at	datetime	Yes	When set to not-null, will override with current datetime

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
updated_at	datetime	Yes	When the skillset was last updated
created_at	datetime	No	When the skillset was created

Type: User

This is a party's user in the system, containing:

Name	Type	Allow Null	Description
id	uuid	No	Party ID (User)
allow_sso	boolean	No	If allow login via SSO
allow_otp	boolean	No	If allow login via guest logins (aka OTP)
system_admin	boolean	No	If user is a system admin

* Not on shallow payloads (ie, only given on get one, responses from create/updates)

Readonly / Optional / Meta properties

Name	Type	Can be Null	Description
first_name	string	No	Max length 150 (readonly)
last_name	string	No	Max length 150 (readonly)
email	string	Yes	The administrative email for the party (readonly)
last_signin	datetime	Yes	Only given on response payload. Last time this
updated_at	datetime	Yes	When the party was last updated
created_at	datetime	No	When the party was created

Type: GeoZone

The following is the geo type object used by territories and locations.

The data has the following constraints:

If WKT (Well-Known Text) is given, then long, lat, and radius MUST be null
If WKT is null, then long/lat will be required

Attribute	Type	Restrictions	Null allowed
id	uuid	Unique id	No
lat	string	Valid latitude, range `-90` to `90`	Yes
long	string	Valid longitude, range `-180` to `180`	Yes
radius	integer	Radius in meters, range >= 0	Yes
wkt	string	Valid WKT (Well known text)	Yes

Type: Address

{
  "valid_addresses": [{
    "name": "Main area",
    "country": "United States"
  }, {
    "name": "Our main catchment area",
    "country": "Canada",
    "region": "Alberta",
    "locale": "Rocky View County"
  }, {
    "name": "Head Office",
    "country": "Canada",
    "region": "Alberta",
    "city": "Calgary",
    "street": "1st St NW",
    "unit": "100",
    "lat": "52.023432",
    "long": "-0.126345"
  }, {
    "name": "Distribution Area",
    "country": "Canada",
    "postal": "T3A 0Z0"
  }]
}

This is an address entry in the system. It is not a first-class citizen, which means, it exists as part of another object, it's meta, or as a consequence. This is due to the non-specific and emphemeral nature of a lot of addresses. The Geo is considered the first-class citizen for geo-related activities.

Address Field	Requires
name	None
country	None
region	`country`
city	`country`, `region`
locale	`country`, `region`
street	`country`, `region`, `city`
unit	`country`, `region`, `city`, `street`
postal	`country`
lat	None
long	None

Type: Identity

The following is the identity object used by parties.

Attribute	Type	Restrictions	Null allowed
id	email	Valid Email	No
suspended_at	datetime	None	Yes

Type: Key Value

A common format for key/value data. Value has a max length of 500. If more data is required, consider if this is the best way of holding such data.

Attribute	Type	Description
key	string	Key for the data, max 150 length
val	string	Value of the data, max 500 length

Batch Error Output

For batch update endpoints, errors will be given in the response. An empty array generally means there were no failures.

A batch error output will adopt the following format:

{
  "errors": [{
    "id": "<uuid>", // The ID of the object which caused the error
    "code": "<error-code>", // The error code, ie 'eGroupNotFound'
    "msg": "<message>" // The human readible error message
  }, {
    ... more errors ...
  }]
}

Output

Different endpoints will return a different kind of output format

All list output will adopt the following format:

{
  "data": [{
    ... data for the object ...
  }, {
    ... data for the object ...
  }],
  "pagination": {
    // Pagination
    "page": 0,
    "per_page": 10,
    "total": 200
  },
  "sort": [{
    // Sort is generally an array, to support single
    // sorts and multiple sort.
    "field": "name",
    "direction": "asc" // Either asc or desc
  }],
  "warnings": [
    // Warnings are single strings - mostly just
    // for developer feedback and not for the user.
    "This is a warning"
  ]
}

For GET One, Create (POST), Update (PUT) will follow the format:

{
  "data": {
    ... data for the object ...
  },
  "warnings": [
    // Warnings are single strings - mostly just
    // for developer feedback and not for the user.
    "This is a warning"
  ]
}

Errors

{
  "errors": [{
    "code": "errorCode",
    "message": "errorMessage"
  }]
}

The following HTTP standard error codes are in use with the API:

Error Code	Meaning
400	Bad Request -- Your request is invalid.
401	Unauthorized -- You need to authenticate or your token has expired.
403	Forbidden -- The request has is forbidden for the given token or token is invalid
404	Not Found -- The specified URL could not be found.
405	Method Not Allowed -- The method/verb for the given URL is not permitted.
406	Not Acceptable -- You requested a format that isn't json.
410	Gone -- The resource requested has been removed from our servers.
418	I'm a teapot.
429	Too Many Requests -- Too many requests, you're rate limited.
500	Internal Server Error -- We had a problem with our server. Try again later.
503	Service Unavailable -- We're temporarily offline for maintenance. Please try again later.

In most cases, errors will be an array of 1. However, in somecases, it will be possible to give more than one error message per response.

See the individual resources for a list of possible error messages for each endpoint.

Introduction

Notes on Retrieving Data

Authentication

Basic schema information

Permissions

Auth

POST Initiate guest login session

POST Confirm guest login session with OTP

Assets

LIST Assets

HTTP Request

Query Parameters

Include Parameters

Sorting fields

LIST Asset Types

HTTP Request

GET an Asset

HTTP Request

URL Parameters

Error Responses

Include Parameters

CREATE a new Asset

HTTP Request

Parameters

Error Responses

UPDATE an Asset

HTTP Request

URL Parameters

Parameters

Error Responses

BATCH UPDATE Assets

HTTP Request

Accepted PATCH Parameters

Error Responses

Config

GET config

GET Theme Config

Contracts

LIST contracts

HTTP Request

Query Parameters

Embed/Include Parameters

Sorting fields

LIST Contract Roles

HTTP Request

GET a Contract

HTTP Request

URL Parameters

Embed/Include Parameters

Error Responses

CREATE a new Contract

HTTP Request

Parameters

Error Responses

UPDATE a Contract

HTTP Request

URL Parameters

Parameters

Error Responses

BATCH UPDATE Contracts

HTTP Request

Accepted PATCH Parameters

Error Responses

DELETE a Contract

HTTP Request

Error Responses

Datazones

LIST DataZones

HTTP Request

Query Parameters

Embed/Include Parameters

Sorting fields

LIST GeoZones for DataZone

HTTP Request

GET a DataZone

HTTP Request

URL Parameters

Embed/Include Parameters

Error Responses

CREATE a DataZone
